Product Details:
|
| Size: | 27 Inch | Resolution: | 1920×1080 |
|---|---|---|---|
| Luminance: | 400 Cd/m² (Typ.) | Contrast Ratio: | 1000 : 1 (Typ.) (TM) |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) | Response: | 14 (Typ.)(Tr+Td) Ms |
| Color Depth: | 16.7M 72% NTSC | Work Mode: | AHVA, Normally Black, Transmissive |
| Refresh Rate: | 60Hz | Touchscreen: | Without |
| High Light: | auo lcd screen,auo lcd display |
||
2.Display Characteristics
| Items | Unit | Specifications |
| Screen Diagonal | [inch] | 27” |
| Active Area | [mm] | 597.888 (H) x 336.312 (V) |
| Resolution | 1920 x1080 | |
| Pixel Pitch | [mm] | 0.3114(triad)x0.3114 |
| Pixel Arrangement | R.G.B. Vertical Stripe | |
| Display Mode | AHVA | |
| Nominal Input Voltage VDD | [Volt] | 5V |
Power Consumption |
[Watt] | Total= 29W (Typ.) (LCD = 2.5W, BLU = 26.5W) |
| Weight | [Grams] | 2865 |
| Physical Size | [mm] | 611.48(H) x 355.81(V) x 12.81(D) typ. |
| Electrical Interface | Dual Channel LVDS | |
| Surface Treatment | Anti-Glare treatment | |
| Support Color | 16.7M colors (6bit + Hi-FRC) | |
Temperature Range Operating Storage (Non-Operating) |
[oC] [oC] | 0 to +50 -20 to +60 |
| RoHS Compliance | RoHS Compliance |
| Item | Unit | Conditions | Min. | Typ. | Max. | Note | |
| White Luminance | cd/m2 | ILED=80mA(center point) | 320 | 400 | - | 1 | |
| Uniformity | % | 9 points | 20 | 2,3 | |||
| Contrast Ratio | -- | 700 | 1000 | - | 4 | ||
Response Time | msec | Rising | - | - | - | | |
| Falling | - | - | - | ||||
| Rising + Falling | - | 14 | 25 | ||||
Viewing Angle | degree | Horizontal CR >= 10 | (Right) | 75 | 89 | - | |
| (Left) | 75 | 89 | - | ||||
| Vertical CR >= 10 | (Upper) | 70 | 89 | - | |||
| (Lower) | 70 | 89 | - | ||||
Color / Chromaticity Coordinates (CIE 1931) | -- | Red x | TBD | ||||
| Red y | TBD | ||||||
| Green x | TBD | ||||||
| Green y | TBD | ||||||
| Blue x | TBD | ||||||
| Blue y | TBD | ||||||
| White x | 0.283 | 0.313 | 0.343 | ||||
| White y | 0.299 | 0.329 | 0.359 | ||||
| Color Gamut | % | 72 | |||||
4. Signal Description
The module using a pair of LVDS receiver SN75LVDS82(Texas Instruments) or compatible.
LVDS is a differential signal technology for LCD interface and high speed data transfer device.
Transmitter shall be SN75LVDS83(negative edge sampling) or compatible. The first LVDS port(RxOxxx) transmits odd pixels while the second LVDS port(RxExxx) transmits even pixels.
