Product Details:
|
Size: | 19 Inch | Screen Type: | LCM , A-Si TFT-LCD |
---|---|---|---|
Luminance: | 700 (Typ.)(cd/m²) | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) |
Contrast Ratio: | 1000 : 1 (Typ.) (TM) | Color Depth: | 16.7M 72% NTSC |
Signal Type: | LVDS (2 Ch, 8-bit) , Connector , 30 Pins | Touchscreen: | Without |
High Light: | auo display panel,auo lcd screen |
2.Display Characteristics
Items | Unit | Specifications |
Screen Diagonal | [inch] | 19.0" |
Active Area | [mm] | 376.32 (H) x 301.06 (V) |
Resolution | 1280(x3) x 1024 | |
Pixel Pitch | [mm] | 0.294 (per one triad) x 0.294 |
Pixel Arrangement | R.G.B. Vertical Stripe | |
Display Mode | Normally Black, AHVA | |
Nominal Input Voltage VDD | [Volt] | +5.0 V |
Power Consumption | [Watt] | Logic: max. 4 W@ white pattern BL power: max. 25.2 W |
Weight | [Grams] | 1700 +/- 150g |
Physical Size | [mm] | 396 (H) x 324 (V) x 15.3 (D) (Typ) |
Electrical Interface | LVDS | |
Surface Treatment | Anti-Glare treatment | |
Support Color | 16.7M colors (8bit) | |
Temperature Range Operating Storage (Non-Operating) |
[oC] [oC] |
0 to +50 -20 to +60 |
RoHS Compliance | Yes |
3.Optical Characteristics
Item | Unit | Conditions | Min. | Typ. | Max. | Note | |
White Luminance | cd/m2 | Center point (at LED= 55mA) | 560 | 700 | --- | 1 | |
Uniformity | % | 9 points | 80 | --- | --- | 2,3 | |
Contrast Ratio | -- | 600 | 1000 | 4 | |||
Response Time | msec | Rising | - | 13 | 18 | | |
Falling | - | 12 | 17 | ||||
Rising + Falling | - | 25 | 35 | ||||
Viewing Angle | degree | Horizontal CR >= 10 | (Right) | 85 | 89 | --- | |
(Left) | 85 | 89 | |||||
Vertical CR >= 10 | (Upper) | 85 | 89 | ||||
(Lower) | 85 | 89 | |||||
Color / Chromaticity Coordinates (CIE 1931) | -- | Red x | 0.621 | 0.651 | 0.681 | ||
Red y | 0.313 | 0.343 | 0.373 | ||||
Green x | 0.272 | 0.302 | 0.332 | ||||
Green y | 0.581 | 0.611 | 0.641 | ||||
Blue x | 0.125 | 0.155 | 0.185 | ||||
Blue y | 0.045 | 0.075 | 0.105 | ||||
White x | 0.283 | 0.313 | 0.343 | ||||
White y | 0.299 | 0.329 | 0.359 | ||||
Color Gamut | % | --- | 72% | --- |
