| Panel Brand: | AUO | Diagonal Size: | 27.0 Inch |
|---|---|---|---|
| View Direction: | Symmetry | Luminance: | 800 Cd/m² (Typ.) |
| Type: | A-Si TFT-LCD, LCM | Configuration: | RGB Vertical Stripe |
| Treatment: | Antiglare | Operating Mode: | AHVA, Normally Black |
| High Light: | auo display panel,auo lcd display |
||
AUO G270ZAN01.0 27 inch LCM 3840×2160 for Industrial Application
AUO G270ZAN01.0 Mechanical Details
| Pixel Features : |
Resolution
3840(RGB)×2160, UHD
Dot Pitch(mm)
0.05175×0.15525 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.15525×0.15525 (H×V)
|
|---|---|
| Mechanical Size : |
Active Area(mm)
596.16(H) × 335.14(V)
Bezel Area(mm)
602.0(H) × 340.4(V)
Outline Dim.(mm)
630(H) × 368.2(V)
Depth(mm)
22/23.4 (Typ./Max.)
|
| Outline Features : |
Form Style
Flat Rectangle Display
Shape Style
-
Aspect Ratio
16:9 (H:V)
Orientation
Landscape type
|
| Mounting : |
Side mounting holes (4-M3) on left, right bezel
|
| Other Spec : |
Weight
3.40Kgs (Typ.)
Treatment
Antiglare
|
| Basic Information : |
Luminance(cd/m²)
800 (Typ.)
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
AHVA, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
16 (Typ.)(Tr+Td)
|
|---|---|
| Color Performance : |
White Coordinate
Wx:0.313; Wy:0.329
Display Colors
1.07B (8-bit + Hi-FRC)
Color Gamut
90% NTSC (CIE1931)
White Uniformity
1.18/1.25 (Typ./Max.)(9 points)
|
| Dispaly Performance : |
Outdoor Visibility
Sunlight Readable
Transmissivity
-
|
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 5 pcs / box | 20.0 Kgs | 730×265×470 mm (L×W×H) |
