Product Details:
|
| Panel Brand: | AUO | Panel Size: | 15.6 Inch |
|---|---|---|---|
| Best View On: | Symmetry | Frequency: | 60Hz |
| Weight: | 600/660g | Pixel Format: | RGB Vertical Stripe |
| Touch Screen: | Without | Panel Type: | A-Si TFT-LCD , LCM |
| High Light: | auo lcd screen,auo lcd display |
||
| Panel Size : | 15.6 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 1920(RGB)×1080, FHD | RGB Vertical Stripe | 0.05975×0.17925 mm | 0.17925×0.17925 mm | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 344.16×193.59 mm | 347.06×196.49 mm | 363.8×215.9 mm | 8.8 (Typ.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle Display | 16:9 (W : H) | Landscape type | - | |
| Fixation : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 600/660g (Typ./Max.) | Hard coating (2H), Reflection 1.5% (Typ.) | ||
Our Advantage
As one of the biggest multiple electronic components & LCD panel distributors in China, we are expert in plenty of branded LCD panels, products include but not limited to:
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 500 cd/m² (Typ.) | AHVA, Normally Black, Transmissive | 1000:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 89/89/89/89 (Typ.)(CR≥10) | Symmetry | 25 (Typ.)(Tr+Td) (ms) | |
| Dispaly Color : | Color Gamut | Color Amount | White color Chromaticity |
| 75% NTSC (CIE1931) | 16.2M (6-bit + FRC) | Wx:0.313; Wy:0.329 | |
| Luminance Variation : | 1.25/1.33 (Typ./Max.)(9 points) | ||
| Package Carton : | Amount | Weight | Carton Size |
|---|---|---|---|
| 16 pcs / box | 13.2 Kgs | 450×375×319 mm (L×W×H) |
FAQ
Q1: How do we place an order?
A1: Please kindly send us an email specifying the item No., replacements, quantity, other specifications for the Hard disk to place an order.
Q2: How do we make the payment?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: What's the delivery time?
A3: The delivery time is normally 1-3 working days after payment.
Q4: How would the goods be shipped?
A4: We ship via DHL, UPS, TNT and others.
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| H546DAN07.3 | AUO | 5.5" | 1080×1920 |
| M270HVN02.3 CELL | AUO | 27.0" | 1920×1080 |
| M270HVN02.2 CELL | AUO | 27.0" | 1920×1080 |
| M270HVN02.1 CELL | AUO | 27.0" | 1920×1080 |
| M270DTN01.0 CELL | AUO | 27.0" | 2560×1440 |
| T320HVN05.7 CELL | AUO | 31.5" | 1920×1080 |
| T320HVN05.4 CELL | AUO | 31.5" | 1920×1080 |
| T215HVN01.2 CELL | AUO | 21.5" | 1920×1080 |
| B070ATN02.0 CELL | AUO | 7.0" | 600×1024 |
We also have other industrial LCD panels, pls contact to us for the further information:
Contact Person: savvy,ren
Tel: +8613302928193
