LB104S01-TL04 LG LCD Screen 10.4 Inch Normally White Hard Coating Antiglare Surface

LB104S01-TL04 LG LCD Screen 10.4 Inch Normally White Hard Coating Antiglare Surface

LB104S01-TL04 LG LCD Screen 10.4 Inch Normally White Hard Coating Antiglare Surface

Product Details:

Place of Origin: Japan
Brand Name: Kyocera
Certification: ISO9001
Model Number: LB104S01-TL04

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 2-3 working days after payment confirmation
Payment Terms: T/T, Western Union,paypal
Supply Ability: 100 PCS / DAY
Contact Now
Detailed Product Description
Panel Type: A-Si TFT-LCD Panel Size: 10.4 Inch
Resolution: 1024×768 Outline: 236×174.3×7.4 Mm
Contrast Ratio: 500:1 (Typ.) Frequency: 60Hz

LB104S01-TL04 LG Display 10.4 inch, 800×600 Normally White Surface Antiglare, Hard coating (3H)



LB104S01-TL04 Basic Information

Panel Model LB104S01-TL04
Panel Brand LG Display
Descrition a-Si TFT-LCD ,10.4 inch, 800×600
Panel Type a-Si TFT-LCD
Model Alias LB104S01 (TL)(04)
Operating Temperature 0 ~ 50 °C
Storage Temperature -20 ~ 60 °C



LB104S01-TL04 Mechanical Features

Dot Resolution 800(RGB)×600 (SVGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 96 PPI
Aspect Ratio 4:3 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.088×0.264 mm (H×V)
Pixel Pitch 0.264×0.264 mm (H×V)
Weight 400/410g (Typ./Max.)
Surface Antiglare, Hard coating (3H)
Active Area 211.2×158.4 mm (H×V)
Bezel Area 214.2×161.8 mm (H×V)
Outline Dimension 224.5×172 mm (H×V)
Outline Depth 7.2±0.5 mm
Holes & Brackets Side mounting holes (4-M2)
Landscape or Portrait Landscape type
Touch Panel Embeded (4-wire Resistive)



LB104S01-TL04 Optical Features

Display Mode TN, Normally White, Transmissive
Brightness 200 cd/m² (Typ.)
Contrast Ratio 400 : 1 (Typ.) (Transmissive)
Display Color 262K (6-bit)
Response Time 6/19 (Typ.)(Tr/Td)
Viewing Angle 65/65/45/55 (Min.)(CR≥10) (L/R/U/D)
Viewing Direction 6 o'clock
White color Chromaticity Wx:0.305; Wy:0.320
White Variation 1.40 (Max.)(9 points)
Sunlight Readable N



Our advantages in the LCD Screen market:
1.Better price
2.Fast delivery
3.Top quality
4.First class after - sales service
5.No memory effect
6.Sourcing lines & Distributors for the EOL LCD.


Shipment for the LCD Display Panels:
1. Safe & Professional package for our LCD panels.
2. We can ship to you by UPS/FEDEX/DHL/TNT and so on. Other shipping terms can also be arranged according to specific requirements.
3. We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4. All our LCD panel will be tested pcs by pcs before been shipped out.


LB104S01-TL04 Backlight System

Lamp Position Edge light type (Bottom side)
Lamp Type CCFL
Lamp Amount 1 pcs
Lamp Shape Straight
Lamp Life Time 20K(Min.) (Hours)
Lamp Voltage 488/500/640V (Min./Typ./Max.)
Lamp Current 2.0/6.0/6.5mA (Min./Typ./Max.)
Lamp Operating Frequency 45/60/80KHz (Min./Typ./Max.)
Lamp Startup Voltage 845/1015V (Max.)(Ta=+25/0℃)
Lamps Power Consumption 3.0/3.3W (Typ./Max.)
Interface Type Connector
Lamp Driver Board No
