LM238WF2-SLK1 LG LCD Panel 23.8 Inch Resolution 1920×1080 Normally Black Frequency 60Hz

Certification
China N&S ELECTRONIC CO., LIMITED certification
China N&S ELECTRONIC CO., LIMITED certification
Customer Reviews
We've come back full of excellent memories, N&S is a very good organisation. Really expert for LCDs.

—— Andy

We'd like to praise the service we received from this company who faultlessly organised our LCD panel supply line.

—— M. H. Thatcher

If I plan another LCD panel order I shan't hesitate to contact you again.

—— Alejandro

I'm Online Chat Now

LM238WF2-SLK1 LG LCD Panel 23.8 Inch Resolution 1920×1080 Normally Black Frequency 60Hz

LM238WF2-SLK1 LG LCD Panel 23.8 Inch Resolution 1920×1080 Normally Black Frequency 60Hz
LM238WF2-SLK1 LG LCD Panel 23.8 Inch Resolution 1920×1080 Normally Black Frequency 60Hz

Large Image :  LM238WF2-SLK1 LG LCD Panel 23.8 Inch Resolution 1920×1080 Normally Black Frequency 60Hz

Product Details:
Place of Origin: KOREA
Brand Name: LG Display
Certification: ISO9001
Model Number: LM238WF2-SLK1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: Western Union, T/T, MoneyGram, T/T
Supply Ability: 500PCS/DAY

LM238WF2-SLK1 LG LCD Panel 23.8 Inch Resolution 1920×1080 Normally Black Frequency 60Hz

Description
Panel Type: A-Si TFT-LCD , LCM Panel Size: 23.8 Inch
Resolution: 1920×1080 Brightness: 250 Cd/m² (Typ.)
Surface: Antiglare, Hard Coating (3H) Input Voltage: 5.0V (Typ.)
High Light:

lg display panel

,

lg lcd display

LM238WF2-SLK1 LG Display LCD Panel 23.8 inch resolution 1920×1080 Normally Black Frequency 60Hz



LM238WF2-SLK1​  Specification

  • Brand                         LG Display
  • Model                         LM238WF2-SLK1
  • Diagonal Size           23.8 inch
  • Type                           a-Si TFT-LCD, LCM
  • Pixel Format             1920(RGB)×1080 [FHD]
  • Configuration            RGB Vertical Stripe
  • Active Area               527.04(H)×296.46(V) mm
  • Outline Dim.              540.2(H)×315.6(V) ×13.4(D) mm
  • Bezel Area                530.3(H)×299.7(V) mm
  • Treatment                 Antiglare, Hard coating (3H)
  • Luminance                250 cd/m² (Typ.)
  • Contrast Ratio          1000:1 (Typ.) (TM)
  • View Directio            Symmetry
  • Response Time       14 (Typ.)(G to G)
  • Viewing Angle          89/89/89/89 (Typ.)(CR≥10)
  • Operating Mode       AH-IPS, Normally Black, Transmissive
  • Support Color          16.7M 72% (CIE1931)
  • Light Source             WLED [15S4P] , 30K hours , W/O Driver
  • Weight                     1.91/2.01Kgs (Typ./Max.)
  • Frame Rate              60Hz
  • Touch Panel              Without
  • Interface Type          30 pins LVDS (2 ch, 8-bit) , Connector
  • Power Supply           5.0V (Typ.)
  • Environment             Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C


Guarantee:
(1) All items will be strictly tested and shipped with safe & professional package.
(2) We have 12 months warranty for each LCD screen panel, depend on the different LCD panel models.
(3) We will do our best to solve any possible problems for your after sale sevice. Please contact with us if any problems.

FAQ
Q1: What's the quality of your Hard Disk?
A: Various brands for hard disk etc. We are available to meet your different requirements.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 12-month warranty after shipping to assure you a stable performance.
Q4: How long is the lead time?
A: The lead time is about 2-3 working days after receipt of payment.
Q5: Do you accept sample order?
A:Yes, sample order is welcome.
Q6: How can I get the quotation?
A: Please enquire via Skype, Email, Whatsapp or telephone. You will get reply within 24 hours.

Here comes our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LC470DUT-SEF2 LG Display 47" 1920×1080
LC550EGY-SHM1 LG Display 55" 3840×2160
LC550EQK-FGK3 LG Display 55" 3840×2160
LC420DUJ-SGE3 LG Display 42" 1920×1080
LH450WX3-SH01 LG Display 4.5" 720×1280
LC490EQJ-SGE2 LG Display 49" 3840×2160
LH470WX3-SH02 LG Display 4.7" 720×1280
LH600WX1-SH01 LG Display 6.0" 720×1280
LC490EQJ-SGK1 LG Display 49" 3840×2160
LC420EQJ-SGE2 LG Display 42" 3840×2160
