Product Details:
|
| Panel Brand: | OPTREX | Panel Model: | DMC-16117A |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD , LCM | Panel Size: | 2.4 Inch |
| Resolution: | 16 Characters × 1 Lines | Display Mode: | TN, Reflective |
| High Light: | optrex lcd panel,lcd module display |
||
2.4 inch DMC-16117A OPTREX LCD Panel 3.2×5.95 mm Character Size
DMC-16117A Detail
| Panel Brand : | OPTREX | |
| Panel Model : | DMC-16117A | |
| Panel Type : | TN-LCD , LCM | |
| Panel Size : | 2.4 inch | |
| Display Format : | 16 characters × 1 lines | |
| Display Mode : | TN, Reflective | |
| Display Fonts : | 5×8 dots | |
| Character Size : | 3.2×5.95 mm | |
| Character Pitch : | 3.75×5.95 mm | |
| Active Area : | 59.4×5.95 mm | |
| Bezel Area : | 64.5×13.0 mm | |
| Outline : | 80×36×10 mm | |
| Brightness : | ||
| Contrast Ratio : | 3.5:1 (Typ.)(Reflective) | |
| Display Colors : | Monochrome | |
| Response Time : | 180/130 (Typ.)(Tr/Td) | |
| Lamp Type : | No B/L | |
| Signal Interface : | 8-bit parallel , 14 pins | |
|
5.0V (Typ.) |
Our Advantage :
>>Quality Guarantee:
Our LCD Panels are 100% original and brand new!
Warranty : 12 months
You can enjoy the real panels directly from the LCD panel brand distributor.
>>Packing Guarantee:
All the products are in original package from original factory directly, and all the LCD panel packages with labels and serial number!
>>Delivery Guarantee:
We have international logistic center in HK, so we can arrange fastest and most convenient delivery for you!
>>After-Sale service
We have many years good experience on display solution.
Any question, we will reply you within 12 hours.
FAQ
Q1: Can I place sample order first?
A1: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
Q2: How could I pay them?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: How to place the order?
A3: Please send us your purchase order by e-mail, whatsapp or Skype or you can ask us to send you a Proforma Invoice for your order.
Q4: How long can I get my order?
A4: For samples, we will finish production and ship within 1-3 working days. For bulk orders, that will base on the order quantity.
Q5: How to send us the products?
A5: We usually use DHL, UPS, FedEx to ship our LCD screen replacements to our clients.
| Panel Size : | 2.4 inch |
| Display Format : | 16 characters × 1 lines |
| Display Fonts : | 5×8 dots |
| Character Size : | 3.2×5.95 mm |
| Character Pitch : | 3.75×5.95 mm |
| Aspect Ratio : | >3:1 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.65×0.75 mm (H×V) |
| Active Area : | 59.4×5.95 mm (H×V) |
| Bezel Area : | 64.5×13.0 mm (H×V) |
| Outline Dimension : | 80×36 mm (H×V) |
| Outline Depth : | 10.0 (Max.) mm |
| Holes & Brackets : | Face mounting holes (4-Φ2.8) |
| Touch Panel : | Without |
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk
| Panel Model | Brand | Size | Resolution |
| SXGA060SG | OLiGHTEK | 0.6" | 1280×1024 |
| SXGA060SW | OLiGHTEK | 0.6" | 1280×1024 |
| SXGA060SC | OLiGHTEK | 0.6" | 1280×1024 |
| SVGA097SG | OLiGHTEK | 0.97" | 800×600 |
| SVGA097SW | OLiGHTEK | 0.97" | 800×600 |
| SVGA097SC | OLiGHTEK | 0.97" | 800×600 |
| SVGA060SG | OLiGHTEK | 0.6" | 800×600 |
| SVGA060SW | OLiGHTEK | 0.6" | 800×600 |
| SVGA060SC | OLiGHTEK | 0.6" | 800×600 |
| SVGA050SG | OLiGHTEK | 0.5" | 800×600 |
| SVGA050SW | OLiGHTEK | 0.5" | 800×600 |
| SVGA050SC | OLiGHTEK | 0.5" | 800×600 |
| SXGA060SG | OLiGHTEK | 0.6" | 1280×1024 |
| SXGA060SW | OLiGHTEK | 0.6" | 1280×1024 |
| SXGA060SC | OLiGHTEK | 0.6" | 1280×1024 |
DMC-16117A Picture
