Product Details:
|
Panel Brand: | TIANMA | Panel Type: | A-Si TFT-LCD |
---|---|---|---|
Active Area: | 132.48×99.36 Mm | Outline: | 158×120.04 Mm |
Surface: | Antireflection | Frequency: | 60Hz |
High Light: | black and white lcd display,lcd panel screen |
Normally White TM065QDHG01 Tianma 6.5 inch 132.48×99.36 mm Active Area LCD display panel
Up to now, over hundreds of aerospace, power management, network, communications, instrumentation and consumer electronics, etc are benefiting from our service and LCD screen panels.
We can do for you:
Why Choose US:
1. Prompt reply within 12 hours.
2. Understand inquiry in any language.
3. Products with top quality.
4. Very competitive prices.
5. 6-year experience in industrial LCD Screen replacements.
6. Distributor of famous brands Panel: Samsung, LG, Sharp, AUO, TPO, Tianma, Mitsubishi and more.
7. Fabulous after-sale service.
TM065QDHG01 Information
Panel Model | TM065QDHG01-00 |
---|---|
Panel Brand | TIANMA |
Descrition | a-Si TFT-LCD ,6.5 inch, 640×480 |
Panel Type | a-Si TFT-LCD |
Display Mode | TN, Normally White, Transmissive |
Active Area | 132.48×99.36 mm |
Outline | 158×120.04 mm |
Surface | Antireflection |
Contrast Ratio | 500:1 (Typ.) |
Display Colors | 262K (6-bit) , CIE1931 50% |
Response Time | 20 (Typ.)(Tr+Td) |
Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) (L/R/U/D) |
Frequency | 60Hz |
Lamp Type | 6S3P WLED Without Driver |
Signal Interface | Parallel RGB (1 ch, 6-bit) , 31 pins |
Input Voltage | 3.3/5.0V (Typ.)(VCC) |
TM065QDHG01-00 Mechanical Features
Dot Resolution | 640(RGB)×480 (VGA) |
---|---|
Pixel Configuration | RGB Vertical Stripe |
Pixel Density | 122 PPI |
Aspect Ratio | 4:3 (H:V) |
Form Factor | Flat Rectangle Display |
Dot Pitch | 0.069×0.207 mm (H×V) |
Pixel Pitch | 0.207×0.207 mm (H×V) |
Weight | TBD |
Surface | Antireflection |
Active Area | 132.48×99.36 mm (H×V) |
Bezel Area | 135.48×102.36 mm (H×V) |
Outline Dimension | 158×120.04 mm (H×V) |
Outline Depth | 7.0 (Typ.) mm |
Holes & Brackets | Rear mounting holes (4-R1.75) |
Landscape or Portrait | Landscape type |
Touch Panel | Without |
Here comes our other LCD panels stock for your easy reference:
Panel Model | Brand | Size | Resolution |
TM240160XCFWGRA | Tianma | 2.2" | 240×160 |
TM128128F6CCWGWC1 | Tianma | 1.44" | 128×128 |
TM12864G3CCWGWA-1 | Tianma | 2.4" | 128×64 |
TM050XYSP02 | Tianma | 5.0" | 540×960 |
TM050JYHN11-00 | Tianma | 5.0" | 720×1280 |
