550CD/M2 AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768

550CD/M2  AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768
550CD/M2  AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768 550CD/M2  AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768

Large Image :  550CD/M2 AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768

Product Details:
Place of Origin: Japan
Brand Name: AUO LCD Displays
Certification: ISO9001
Model Number: G150XG02 V1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD
Packaging Details: Standard packing
Delivery Time: 1-2days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,HKIN ESCROW .....
Supply Ability: 500PCS/DAY

550CD/M2 AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768

Description
Product Number: G150XG02 V1 Resolution: 1024×768
C/R: 700:1 Backlight: CCFL
Brightness: 550 SIZE: 15.0"
High Light:

auo display panel

,

auo lcd screen

550CD/M2 AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768





Panel Brand : AUO
Panel Model : G150XG02 V1
Panel Type : a-Si TFT-LCD , LCM
Panel Size : 15.0 inch
Resolution : 1024(RGB)×768 , XGA
Display Mode : TN, Normally White, Transmissive
Active Area : 304.128×228.096 mm
Outline : 326.5×253.5×14.6 mm
Surface : Antiglare, Hard coating (3H)
Brightness : 550 cd/m² (Typ.)
Contrast Ratio : 700:1 (Typ.)
Display Colors : 262K/16.2M (6-bit / 6-bit + FRC) , CIE1931 65%
Response Time : 5.7/2.3 (Typ.)(Tr/Td)
Viewing Angle : 80/80/70/70 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 4 pcs CCFL Without Driver
Signal Interface : LVDS (1 ch, 6/8-bit) , 20 pins





AUO G150XG02 V1 Basic Information

Panel Brand : 550CD/M2  AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768 0
Panel Model : G150XG02 V1
Model Alias : G150XG02 V.1
Panel Type : a-Si TFT-LCD , LCM
Application :
  • 550CD/M2  AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768 1
Operating Temperature : -30 ~ 85 °C
Storage Temperature : -30 ~ 85 °C
RoHS : 550CD/M2  AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768 2
Specific Feature :
  • Antiglare Sureface
  • 6/8 bit Selectable
  • Wide Viewing Angle
  • Landscape type
  • Wide Temprature
  • Hight Brightness
  • Lamp Repaceable
  • Lamp life ≥ 50K hours
  • 180 Reverse





The reasons you choose us



1).More competitive price! As aprofessional LCD Distributor,we have our own souring lines &solutions to support us for the more competitive service, not only the price, but also the stock for the hard-to-find LCD panels.

2).Great quality! All LCD Screen we sent are with good quality guarantee,100% quality check and full one year warranty!
3).Fast delievery! Delivery time will be faster than others.
4).Great shipping service! We have cooperated with DHL,UPS and EMS for long time,so we could promise save much more money on the shipping cost and betterservice is offered!
5).Best sale-service!Professional team to service with you before sale, on sale & after service.



550CD/M2  AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768 12550CD/M2  AUO 15.0 inch TFT LCD Screen G150XG02 V1 XGA 1024(RGB)*768 13
