Product Details:
|
| Model:: | G190EG01 V0 | Size:: | 19.0" |
|---|---|---|---|
| Brightness :: | 450 Cd/m² (Typ.) | Resolution :: | 1280(RGB)×1024 , SXGA |
| High Light: | auo lcd screen,auo lcd display |
||
G190EG01 V0 1280*1024 Tft Lcd Module , 19 Inch Industrial Lcd Screen 450 Cd / M² Brightness
| Panel Model | Size | Type | Resolution | cd/m2 |
| M190EG01 V2 | 19.0" | LCM | 1280×1024 | 300 |
| M190EG01 V3 | 19.0" | LCM | 1280×1024 | 300 |
| LM190E05-SL03 | 19.0" | LCM | 1280×1024 | 230 |
| LM190E05-SL02 | 19.0" | LCM | 1280×1024 | 280 |
| MT190EN02 V.Y | 19.0" | LCM | 1280×1024 | 250 |
| NL128102BC29-01B | 19.0" | LCM | 1280×1024 | 280 |
| HSD190MEN3-A03 | 19.0" | LCM | 1280×1024 | 300 |
| M190EG01 V0 | 19.0" | LCM | 1280×1024 | 300 |
| M190E5-L0G | 19.0" | LCM | 1280×1024 | 270 |
AUO G190EG01 V0 Optical Features
Display Mode : TN, Normally White, Transmissive
Contrast Ratio : 1000 : 1 (Typ.) (Transmissive)
Display Color : 16.7M (6-bit + Hi-FRC)
Color Gamut : 72% NTSC (CIE1931)
Response Time : 3.6/1.4 (Typ.)(Tr/Td); 8 (Typ.)(G to G)
Viewing Angle : 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)
White color Chromaticity : Wx:0.313; Wy:0.329
White Variation : 1.25/1.33 (Typ./Max.)(9 points)
Company Information:
ShenZhen N&S Technology CO., LTD was established in 2010, Speciliazed in the LCD product development / production, we holds the operating philosophy of "quality, service, responsibility, innovation".
Our products have passed the certification of ISO9001 Quality Management Systemin order to improve quality of our products.
We have a wealth of professional experience and strong research and development, always walk in the forefront of the industry in the fierce market competition, with unremitting efforts to achieve development!
