TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type

TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type
TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type

Large Image :  TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type

Product Details:
Place of Origin: SHANGHAI
Brand Name: AUO LCD Panel
Certification: CE
Model Number: G057VN01 V1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: usd
Packaging Details: standard packing
Delivery Time: 24hours
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000

TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type

Description
Model:: G057QN01 V1 Resolution :: 320(RGB)×240 , QVGA
Contrast Ratio :: 800:1 (Typ.) Brightness :: 340 Cd/m² (Typ.)
Signal Interface :: LVDS (1 Ch, 6-bit)
High Light:

auo display panel

,

auo lcd display



TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type




Display Mode : TN, Normally White, Transmissive
Active Area : 115.2×86.4 mm
Outline : 144×104.6 mm
Surface : Antiglare, Hard coating (3H)
Brightness : 700 cd/m² (Typ.)
Contrast Ratio : 800:1 (Typ.)
Display Colors : 262K (6-bit) , CIE1931 50%
Response Time : 15/10 (Typ.)(Tr/Td)
Viewing Angle : 80/80/70/70 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : WLED
Signal Interface : CMOS (1 ch, 6-bit) , 33 pins
Input Voltage : 3.3V (Typ.)(VDD)



Trade Terms:

Payment terms: 100% by T/T when order confirmed
Lead time: 2-5 working days according to the order quantity
Sample lead time: within 3 working days after we get payment.
The price based on FOB Shenzhen,we will offer best discount according to order quantity.
Warranty:offer free spare parts within ONE year.
Offer OEM service for batch orders,to print logo and design box.





5.7", 640×480, 6-bit, TTL, 2D, WLED, HB, Flat, LCM Hot Model



Panel Model Size Type Resolution cd/m2
G057VN01 V2 5.7" LCM 640×480 700
NL6448BC18-01F 5.7" LCM 640×480 800
G057VN01 V1 5.7" LCM 640×480 700
G057VTN01.0 5.7" LCM 640×480 530
NL6448BC18-06F 5.7" LCM 640×480 800
G057VTN01.1 5.7" LCM 640×480 550
NL6448BC18-03F 5.7" LCM 640×480 800
AA057VF12--T1 5.7" LCM 640×480 880
TX14D23VM5BAA 5.7" LCM 640×480 800
AC057VK02 5.7" LCM 640×480 520





TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type 0TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type 1TFT G057VN01 V1 VGA auo lcd screen 640(RGB)*480 WLED Lamp Type 2
