Product Details:
|
| Model:: | G057QN01 V2 | Resolution :: | 320(RGB)×240 , QVGA |
|---|---|---|---|
| Contrast Ratio :: | 800:1 (Typ.) | Brightness :: | 340 Cd/m² (Typ.) |
| Signal Interface :: | LVDS (1 Ch, 6-bit) | ||
| High Light: | auo display panel,auo lcd display |
||
5.7 Inch G057QN01 V2 anti glare lcd screen 320*240 TN LCD CMOS 1ch 6- bit 800 cd / m2
| Panel Brand : | AUO |
| Panel Model : | G057QN01 V2 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 5.7 inch |
| Resolution : | 320(RGB)×240 , QVGA |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 115.2×86.4 mm |
| Outline : | 144×104.6×12.8 mm |
| Surface : | Antiglare, Hard coating (3H) |
| Brightness : | 800 cd/m² (Typ.) |
| Contrast Ratio : | 800:1 (Typ.) |
| Display Colors : | 262K (6-bit) , CIE1931 50% |
| Response Time : | 15/10 (Typ.)(Tr/Td) |
| Viewing Angle : | 80/80/70/70 (Typ.)(CR≥10) (L/R/U/D) |
| Panel Model | Size | Type | Resolution | cd/m2 |
| G057QN01 V2 | 5.7" | LCM | 320×240 | 800 |
| G057QN01 V1 | 5.7" | LCM | 320×240 | 800 |
| PD057VU5 | 5.7" | LCM | 320×240 | 700 |
| NL3224AC36-01F | 5.7" | LCM | 320×240 | 800 |
| TX14D26VM1BAA | 5.7" | LCM | 320×240 | 800 |
| FG050701DWSWBGL1 | 5.7" | LCM | 320×240 | 570 |
| FG050701DWSWBGL3 | 5.7" | LCM | 320×240 | 800 |
| PD057VU7 | 5.7" | LCM | 320×240 | 600 |
| T-55520GD057J-LW-ACN | 5.7" | LCM | 320×240 | 800 |
| COM57T5M26ZSC | 5.7" | LCM | 320×240 | 600 |
