LQ049B5DG01 Sharp LCD Panel 4.9 inch LCM 320×96 350 60:1 262K CCFL TTL

LQ049B5DG01  Sharp LCD Panel 	4.9 inch 	LCM 320×96 350	60:1    262K	CCFL  TTL
LQ049B5DG01  Sharp LCD Panel 	4.9 inch 	LCM 320×96 350	60:1    262K	CCFL  TTL

Large Image :  LQ049B5DG01 Sharp LCD Panel 4.9 inch LCM 320×96 350 60:1 262K CCFL TTL

Product Details:
Place of Origin: korea
Brand Name: Sharp
Certification: ISO9001
Model Number: LQ049B5DG01
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 2-3 Working Days after order confirmation
Payment Terms: Western Union, MoneyGram, T/T
Supply Ability: 500PCS/DAY

LQ049B5DG01 Sharp LCD Panel 4.9 inch LCM 320×96 350 60:1 262K CCFL TTL

Description
Panel Brand: SHARP Panel Model: LQ049B5DG01
Panel Type: A-Si TFT-LCD , LCM Panel Size: 4.9 Inch
Resolution: 320(RGB)×96 Display Mode: TN, Normally White, Transmissive
High Light:

sharp lcd display panels

,

sharp lcd screen

LQ049B5DG01 Sharp LCD Panel 4.9 inch LCM 320×96 350 60:1 262K CCFL TTL



Quality Control:

  1. Visual Inspection

Make sure No damage, No Scratches, No dusty, No light leakage.

  1. Function Inspection

Make sure all functions are 100% tested ok



LQ049B5DG01 Product Information

Panel Brand : SHARP
Panel Model : LQ049B5DG01
Panel Type : a-Si TFT-LCD , LCM
Panel Size : 4.9 inch
Resolution :
320(RGB)×96
Display Mode : TN, Normally White, Transmissive
Active Area : 120×36 mm
Outline : 142×54 mm
Surface :
Antiglare
Brightness : 350 cd/m² (Typ.)
Contrast Ratio : 60:1 (Min.)
Display Colors : 262K (6-bit)
Response Time : 30/50 (Typ.)(Tr/Td)
Viewing Angle : 65/65/40/65 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type :
1 pcs CCFL Without Driver
Signal Interface : Parallel RGB (1 ch, 6-bit) , 30 pins
Input Voltage : 5.0/10.0/-10.0V (Typ.)(VSH/VGH/VGL)



Shipment for the LCD Display Panels:

1. Safe & Professional package for our LCD panels.

2. We can ship to you by UPS/FEDEX/DHL/TNT and so on. Other shipping terms can also be arranged according to specific requirements.

3. We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

4. All our LCD panel will be tested pcs by pcs before been shipped out.



Panel Size : 4.9 inch
Dot Resolution : 320(RGB)×96
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 67 PPI
Aspect Ratio : >3:1 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.125×0.375 mm (H×V)
Pixel Pitch : 0.375×0.375 mm (H×V)
Weight :
110±20g
Surface : Antiglare
Active Area : 120×36 mm (H×V)
Bezel Area : 125.6×41.6 mm (H×V)
Outline Dimension : 142×54 mm (H×V)
Outline Depth : 13.0 (Typ.) mm
Holes & Brackets : Rear mounting holes (4-Ф2.2)
Landscape or Portrait : Landscape type
Touch Panel : Without



Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LQ055T3SX04 SHARP 5.5" 1080×1920
LQ079L1SX06 SHARP 7.9" 1536×2048
LQ079L1SX04 SHARP 7.9" 1536×2048
LQ133M1JW08 SHARP 13.3" 1920×1080
LQ156D1JX02 SHARP 15.6" 3840×2160

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk



LQ049B5DG01 Picture
