800 9.0 inch Chimei LCD Panel AT090TN10 / TFT lcd monitor panel

Certification
China N&S ELECTRONIC CO., LIMITED certification
China N&S ELECTRONIC CO., LIMITED certification
Customer Reviews
We've come back full of excellent memories, N&S is a very good organisation. Really expert for LCDs.

—— Andy

We'd like to praise the service we received from this company who faultlessly organised our LCD panel supply line.

—— M. H. Thatcher

If I plan another LCD panel order I shan't hesitate to contact you again.

—— Alejandro

I'm Online Chat Now

800 9.0 inch Chimei LCD Panel AT090TN10 / TFT lcd monitor panel

800 9.0 inch Chimei LCD Panel AT090TN10 / TFT lcd monitor panel
800 9.0 inch Chimei LCD Panel AT090TN10 / TFT lcd monitor panel 800 9.0 inch Chimei LCD Panel AT090TN10 / TFT lcd monitor panel 800 9.0 inch Chimei LCD Panel AT090TN10 / TFT lcd monitor panel

Large Image :  800 9.0 inch Chimei LCD Panel AT090TN10 / TFT lcd monitor panel

Product Details:
Place of Origin: Japan,Korea
Brand Name: Chimei LCD Panel
Certification: ISO9001
Model Number: AT090TN10
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: T/T, Western Union, MoneyGram, Paypal
Supply Ability: 100 PCS PER DAY

800 9.0 inch Chimei LCD Panel AT090TN10 / TFT lcd monitor panel

Description
Display Mode: TN, Normally White, Transmissive Active Area: 198×111.696 Mm
Outline: 211.1×126.5 Mm Contrast Ratio: 500:1 (Typ.)
Display Colors: 262K/16.7M (6-bit / 6-bit + Hi-FRC) , CIE1931 50% Response Time: 10/15 (Typ.)(Tr/Td)
Viewing Angle: 70/70/50/70 (Typ.)(CR≥10) (L/R/U/D) Lamp Type: WLED
High Light:

tft lcd display

,

lcd monitor panel

800 9.0 inch Chimei LCD Panel AT090TN10 / TFT lcd monitor panel

CHIMEI INNOLUX AT090TN10 General Features

Panel Brand :CHIMEI INNOLUX
Panel Model :AT090TN10
Panel Type :a-Si TFT-LCD , Panel
Panel Size :9.0 inch
Resolution :800(RGB)×480 , WVGA
Display Mode :TN, Normally White, Transmissive
Active Area :198×111.696 mm
Outline :211.1×126.5 mm
Surface :Antiglare
Brightness :250 cd/m² (Typ.)
Contrast Ratio :500:1 (Typ.)
Display Colors :262K/16.7M (6-bit / 6-bit + Hi-FRC) , CIE1931 50%
Response Time :10/15 (Typ.)(Tr/Td)
Viewing Angle :70/70/50/70 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type :WLED
Signal Interface :TTL (1 ch, 6/8-bit) , 50 pins
Input Voltage :3.3/10.4/17.0/-5.0V (Typ.)(DVDD/AVDD/VGH/VGL)


Company Strength:
1. ISO9001 certificated, Factory Direct Supplied
2. RoHS Compliant, Lead Free, Reach Compliant
3. Competitive Price and Short Lead-time
4. Professional Team with Rich Experiences in Design/Mfg/Quality Control
5. Small MOQ Support & Fast Response to Customers
6. Long Product Life Time

Our Service
1. Quality ensurance
100% original new and A grade,
You can enjoy the real panels directly from original factory;
2. Fast reply:
Our well-developed management system enables us to reply any kind of customers' inquiry in 24 hours.
3. Delivery ensurance:
Large Stock System, We have our own warehouses in Shenzhen and HongKong, with comprehensive supply lines.
4. After-Sale Service:
Professional support team to provide effective service, we are young and full of passion!
5. Professional acknowledgement of lcd panels industry to provide customers with effective advise.
We have been in original lcd panels industry for more than 6 years and know the main brands' lcd panel price system very well. What's more, we have our own engineer team to provide our customers guideline for choosing panels for their new projects.
6. Competitive quotation:
We are insistent in lcd panel industry. Our big customers network ensures us to provide large orders regularly for these original factories. What's more, our financial strength enables us to absorb large stock. All these make our price more and more competitive.

Below are our other LCD panels stock for your easy reference:

Panel ModelBrandSizeResolution
ED312TT2E Ink31.2"2560×1440
ES133TE1E Ink13.3"2200×1650
ES133TT2E Ink13.3"2200×1650
ED133TT1E Ink13.3"2200×1650
ED060SD1E Ink6.0"600×800

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

CHIMEI INNOLUX AT090TN10 Mechanical Features

Panel Size :9.0 inch
Dot Resolution :800(RGB)×480 (WVGA)
Pixel Configuration :RGB Vertical Stripe
Pixel Density :104 PPI
Aspect Ratio :16:9 (H:V)
Form Factor :Flat Rectangle Display
Dot Pitch :0.0825×0.2327 mm (H×V)
Pixel Pitch :0.2475×0.2327 mm (H×V)
Weight :253g (Typ.)
Surface :Antiglare
Active Area :198×111.696 mm (H×V)
Bezel Area :201.00×114.7 mm (H×V)
Outline Dimension :211.1×126.5 mm (H×V)
Outline Depth :5.9±0.3 mm
Landscape or Portrait :Landscape type
Touch Panel :Without
