G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless

Certification
China N&S ELECTRONIC CO., LIMITED certification
China N&S ELECTRONIC CO., LIMITED certification
Customer Reviews
We've come back full of excellent memories, N&S is a very good organisation. Really expert for LCDs.

—— Andy

We'd like to praise the service we received from this company who faultlessly organised our LCD panel supply line.

—— M. H. Thatcher

If I plan another LCD panel order I shan't hesitate to contact you again.

—— Alejandro

I'm Online Chat Now

G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless

G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless
G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless

Large Image :  G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless

Product Details:
Place of Origin: TaiWan
Brand Name: AUO
Model Number: G270QAN02.0
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: pls contact us
Packaging Details: standard Packaging
Delivery Time: 5-8 work days
Payment Terms: Western Union,PAPLY,BANK TRANSFER
Supply Ability: 500

G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless

Description
Panel Brand: AUO Panel Model: G270QAN02.0
Panel Size: 27.0" Panel Type: A-Si TFT-LCD, LCM
Resolution: 2560(RGB)×1440, Quad-HD, 108PPI Touch Screen: Without
High Light:

LCM Lcd Panel 27 Inch

,

G270QAN02.0

,

AUO Lcd Panel 27 Inch

G270QAN02.0 AUO 27" LCM 2560×1440 Without Touchscreen And Industrial



AUO G270QAN02.0 Optical Details

Basic Detail :
Luminance
350 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
8/8 (Typ.)(Tr/Td) ms
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
AHVA, Normally Black, Transmissive
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Support Color
16.7M (8-bit)
Color Temperature
6485K
White Variation
1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
76%
sRGB
100% coverage
Adobe RGB
78% coverage
DCI-P3
79% coverage
Rec.2020
57% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
  • G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless 0 Back to Top

AUO G270QAN02.0 Mechanical Details

Pixel Features :
Number of Pixel
2560(RGB)×1440, Quad-HD
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.0777×0.2331 mm
Pixel Pitch(W×H)
0.2331×0.2331 mm [108PPI]
Physical Size :
Active Viewing
596.74(W)×335.66(H) mm
Overall Dim.
606.44(W)×355.56(H) mm
Bezel Opening
-
Overall Depth
10.33/15.03 (Typ./Max.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
16:9
Shape Style
3-side borderless
Fixation :
Rear mounting Pole (14-M3)
Other Detail :
Mass
3.50Kgs (Typ.)
Surface
Antiglare, Hard coating (3H)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct



Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information



Panel Model Brand Size
X139BLB01.0 AUO 1.39"
H381DLN01.0 AUO 3.8"
H497TLB01.4 AUO 5.0"
H163QLN01.0 AUO 1.63"
H139BLN01.2 AUO 1.39"
T320XVN02.F CELL AUO 31.5"
T430HVN01.6 CELL AUO 43"
B101EAN01.2 CELL AUO 10.1"
H497EAN01.0 AUO 5.0"
T320XVN02.C CELL AUO 31.5"
T320HVN05.8 CELL AUO 31.5"
T500HVN07.5 CELL AUO 50"
B070EAN02.0 CELL AUO 7.0"
M320QAN01.0 CELL AUO 32.0"
H546TAN02.0 AUO 5.5"
H598TAN01.0 AUO 6.0"





Packaging & Delivery

Packaging: Safety Package For all of our LCD Screen Panel Replacements.

4. Carton Box.



Details: 1. Antistatic bag

2. Layers of cartons

3. Foam Box



Warranty:

1. All panels’ grade is promised strictly same as original factory’s standard.

2. All brand-new Panels’ electronic functions are guarranted during warranty period of 1 year beginning with the invoice date.

3. We own 6-Year experience in the Medical LCD display, Aerospace LCD screen, Gaming LCD replacements, Military LCD screen, Kiosk LCD Display, Transportation LCD, industrial LCD panel and more.

4. ISO 9001 guarantee.





G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless 1G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless 2
