Medical Imaging TFT AUO LCD Panel 21.5 Inch 6485K G215HAN01.3

Medical Imaging TFT AUO LCD Panel 21.5 Inch 6485K G215HAN01.3
Medical Imaging TFT AUO LCD Panel 21.5 Inch 6485K G215HAN01.3 Medical Imaging TFT AUO LCD Panel 21.5 Inch 6485K G215HAN01.3

Large Image :  Medical Imaging TFT AUO LCD Panel 21.5 Inch 6485K G215HAN01.3

Product Details:
Place of Origin: TaiWan
Brand Name: AUO
Model Number: G215HAN01.3
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: pls contact us
Packaging Details: standard Packaging
Delivery Time: 5-8 work days
Payment Terms: Western Union,PAPLY,BANK TRANSFER
Supply Ability: 500

Medical Imaging TFT AUO LCD Panel 21.5 Inch 6485K G215HAN01.3

Description
Manufacturer: AUO Model Name: G215HAN01.3
Screen Size: 21.5 Inch Screen Type: LCM , A-Si TFT-LCD
Pixel Number: 1920(RGB)×1080 (FHD) 102PPI Touchscreen: Without
High Light:

AUO LCD Panel

,

AUO LCD Panel 21.5 Inch

,

G215HAN01.3

Medical Imaging TFT AUO LCD Panel 21.5 Inch 6485K G215HAN01.3



G215HAN01.3 AUO 21.5" LCM 1920×1080 Without Touchscreen And Industrial,Medical Imaging

AUO G215HAN01.3 Optical Details

Basic Information :
Luminance
250 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
12/10 (Typ.)(Tr/Td) ms
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
AHVA, Normally Black, Transmissive
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Support Color
16.7M (6-bit + Hi-FRC)
Color Temperature
6485K
White Variation
1.18/1.25 (Typ./Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
75%
sRGB
97% coverage
Adobe RGB
76% coverage
DCI-P3
78% coverage
Rec.2020
56% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
  • Medical Imaging TFT AUO LCD Panel 21.5 Inch 6485K G215HAN01.3 0 Back to Top

AUO G215HAN01.3 Mechanical Details

Pixel Features :
Number of Pixel
1920(RGB)×1080, FHD
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.08265×0.24795 mm
Pixel Pitch(W×H)
0.24795×0.24795 mm [102PPI]
Physical Size :
Active Viewing
476.064(W)×267.786(H) mm
Overall Dim.
497.6(W)×292.2(H) mm
Bezel Opening
479.8(W)×271.3(H) mm
Overall Depth
11.0 (Max.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
16:9
Shape Style

Fixation :
Side mounting holes (4-M3) on left, right bezel
Other Detail :
Mass
1.74Kgs (Typ.)
Surface
Antiglare, Hard coating (3H)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct
