Antiglare TFT 12.1" AUO LCD Panel G121STN02.0 3H Hard Coating

Antiglare TFT 12.1" AUO LCD Panel G121STN02.0 3H Hard Coating
Antiglare TFT 12.1" AUO LCD Panel G121STN02.0 3H Hard Coating

Large Image :  Antiglare TFT 12.1" AUO LCD Panel G121STN02.0 3H Hard Coating

Product Details:
Place of Origin: TaiWan
Brand Name: AUO
Model Number: G140HAN01.0
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: pls contact us
Packaging Details: standard Packaging
Delivery Time: 5-8 work days
Payment Terms: Western Union,PAPLY,BANK TRANSFER
Supply Ability: 500

Antiglare TFT 12.1" AUO LCD Panel G121STN02.0 3H Hard Coating

Description
Brand: Brand Model: G140HAN01.0
Diagonal Size: 12.1inch Type: A-Si TFT-LCD , LCM
Pixel Format: 800(RGB)×600 [SVGA] 82PPI Touch Panel: Without
High Light:

12.1" AUO LCD Panel

,

TFT AUO LCD Panel

,

G121STN02.0

Antiglare TFT 12.1" AUO LCD Panel G121STN02.0 3H Hard Coating



G121STN02.0 AUO 12.1" LCM 800×600 Without Touchscreen And Industrial

AUO G121STN02.0 Mechanical Details

Pixel Features : Resolution 800(RGB)×600, SVGA Dot Pitch(mm) 0.1025×0.3075 (H×V)
Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.3075×0.3075 (H×V) [82PPI]
Mechanical Size : Active Area(mm) 246(H) × 184.5(V) Bezel Area(mm) 249(H) × 187.5(V)
Outline Dim.(mm) 260.5(H) × 203(V) Depth(mm) 6.1/9.0 (Typ./Max.)
Outline Features : Form Style Flat Rectangle Outline Shape
Aspect Ratio 4:3 (H:V) Orientation Landscape type
Mounting : Side mounting holes (4-M2) on left, right bezel
Other Spec : Weight 600g (Max.) Treatment Antiglare, Hard coating (3H)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
  • Antiglare TFT 12.1" AUO LCD Panel G121STN02.0 3H Hard Coating 0 Back to Top


AUO G121STN02.0 Optical Details

Basic Information : Luminance(cd/m²) 500 (Typ.) Contrast Ratio 800:1 (Typ.) (Transmissive)
Viewing Angle 80/80/65/75 (Typ.)(CR≥10)  Display Mode TN, Normally White, Transmissive
Best View on 6 o'clock Response(ms) 25/10 (Typ.)(Tr/Td)
Color Performance : White Coordinate X:0.313; Y:0.329 Display Colors 262K/16.2M (6-bit / 6-bit + FRC)
Color Temperature 6485K White Uniformity 1.33 (Max.)(5 points)
1931 Color Gamlt : NTSC Ratio 53% sRGB 72% coverage
Adobe RGB 55% coverage DCI-P3 55% coverage
Rec.2020 39% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
