Mobile Phone Tianma 2.2" LCM LCD Display Panel 240×320 TM022HDHT11

Mobile Phone Tianma 2.2" LCM LCD Display Panel 240×320 TM022HDHT11
Mobile Phone Tianma 2.2" LCM LCD Display Panel 240×320 TM022HDHT11

Large Image :  Mobile Phone Tianma 2.2" LCM LCD Display Panel 240×320 TM022HDHT11

Product Details:
Place of Origin: korea
Brand Name: Tianma
Model Number: TM022HDHT11
Payment & Shipping Terms:
Minimum Order Quantity: 2500
Price: pls contact us
Packaging Details: standard Packaging
Delivery Time: 5-8 work days
Payment Terms: Western Union,PAPLY,BANK TRANSFER
Supply Ability: 2500

Mobile Phone Tianma 2.2" LCM LCD Display Panel 240×320 TM022HDHT11

Description
Panel Brand: TIANMA Panel Model: TM022HDHT11
Panel Size: 2.2 Panel Type: A-Si TFT-LCD , LCM
Resolution: 240(RGB)×320, QVGA, 180PPI Touch Screen: Without
High Light:

LCM LCD Display Panel

,

240x320 LCD Display Panel

,

TM022HDHT11

Mobile Phone Tianma 2.2" LCM LCD Display Panel 240×320 TM022HDHT11



TM022HDHT11 Tianma 2.2" LCM 240×320 Without Touch Screen and Mobile Phone

TIANMA TM022HDHT11 Optical Details

Basic Detail :
Luminance
90 cd/m² (Typ.)
Contrast Ratio
120:1 (Typ.) (Transmissive) 10:1 (Typ.) (Reflective)
Good View at
12 o'clock
Response Speed
35 (Typ.)(Tr+Td) ms
Viewing Angle
40/45/48/45 (Typ.)(CR≥10)
Operating Mode
ECB, Normally White, Transflective
Color Performance :
Chromaticity
Wx:0.273; Wy:0.296
Support Color
262K (6-bit)
Color Temperature
10418K
White Variation
1.25/1.43 (Typ./Max.)(9 points) Mobile Phone Tianma 2.2" LCM LCD Display Panel 240×320 TM022HDHT11 0
Dispaly Performance :
Outdoor Visibility
Sunlight Readable
Transmissivity
-
3D Tech
-
Reflectance
5.5% (Typ.)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct

TIANMA TM022HDHT11 Mechanical Details

Pixel Features :
Number of Pixel
240(RGB)×320, QVGA
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.047×0.141 mm
Pixel Pitch(W×H)
0.141×0.141 mm [180PPI]
Physical Size :
Active Viewing
33.84(W)×45.12(H) mm
Overall Dim.
40.6(W)×56.6(H) mm
Bezel Opening
34.84(W)×46.12(H) mm
Overall Depth
2.7±0.2 mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Portrait type
Aspect Ratio(W:H)
3:4
Shape Style

Other Detail :
Mass
TBD
Surface
Clear, Hard coating (3H)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct
  •

We also have other industrial LCD panels, pls contact to us for the further information



Panel Model Brand Size
TM240160XCFWGRA Tianma 2.2"
TM128128F6CCWGWC1 Tianma 1.44"
TM12864G3CCWGWA-1 Tianma 2.4"
TM050XYSP02 Tianma 5.0"
TM050JYHN11-00 Tianma 5.0"
TM055JYSP08 Tianma 5.5"
TM040XYHP01 Tianma 4.0"
TM055JYSP03 Tianma 5.5"
TM055JYHP03 Tianma 5.5"
TM055JYHP01 Tianma 5.5"
TM046XYHP01 Tianma 4.7"
TL050VGXP01 Tianma 5.0"
TM060JYSP02 Tianma 6.0"
TM045YYSP04 Tianma 4.5"
TM045YYSP02 Tianma 4.5"
TM016XYHP01 Tianma 1.6"
TM050JYSP01 Tianma

5.0"
