370 Cd/M² 12.1" LQ121K1LG11 Hard Coating Sharp LCD Panel

370 Cd/M² 12.1" LQ121K1LG11 Hard Coating Sharp LCD Panel
370 Cd/M² 12.1" LQ121K1LG11 Hard Coating Sharp LCD Panel

Large Image :  370 Cd/M² 12.1" LQ121K1LG11 Hard Coating Sharp LCD Panel

Product Details:
Place of Origin: Korea
Brand Name: Sharp
Model Number: LQ121K1LG11
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: pls contact us
Packaging Details: standard Packaging
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union,PAPLY,BANK TRANSFER
Supply Ability: 1000

370 Cd/M² 12.1" LQ121K1LG11 Hard Coating Sharp LCD Panel

Description
Panel Size: 12.1 Inch Resolution: 1280×800
Brightness: 370 Cd/m² (Typ.) Viewing Angle: 80/80/70/70 (Typ.)(CR≥10)
Operating Temp.: 0 ~ 70 °C Storage Temp.: -25 ~ 70 °C
Display Mode: TN, Normally White, Transmissive Touch Screen: Without
High Light:

Hard Coating Sharp LCD Panel

,

LQ121K1LG11

,

370 Cd/M² Sharp LCD Panel

370 Cd/M² 12.1" LQ121K1LG11 Hard Coating Sharp LCD Panel



Description of Sharp LCD Panel

LQ121K1LG11 is a 12.1 inch diagonal a-Si TFT-LCD display screen product from Sharp, with a built-in CCFL backlight, without backlight driver, without touch screen. On the basis of latest version datasheet LD-20109A which was released out on 1 6 2008, LQ121K1LG11 supports display 1280(RGB)×800 (WXGA) with aspect ratio of 16:10 (W:H), whose pixels are arranged in RGB Vertical Stripe.





Sharp LQ121K1LG11 Mechanical Details

Pixel Features :
Resolution
1280(RGB)×800, WXGA
Dot Pitch(mm)
0.068×0.204 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.204×0.204 (H×V) [124PPI]
Mechanical Size :
Active Area(mm)
261.12(H) × 163.2(V)
Bezel Area(mm)
264.24(H) × 167.2(V)
Outline Dim.(mm)
278(H) × 184(V)
Depth(mm)
11.3±0.5
Outline Features :
Form Style
Flat Rectangle
Shape Style

Aspect Ratio
16:10 (H:V)
Orientation
Landscape type
Mounting :
Side mounting holes (4-M2) on left, right bezel
Other Spec :
Weight
640g
Treatment
Antiglare, Hard coating (3H)

Sharp LQ121K1LG11 Optical Details

Basic Information :
Luminance(cd/m²)
370 (Typ.)
Contrast Ratio
400:1 (Typ.) (Transmissive)
Viewing Angle
80/80/70/70 (Typ.)(CR≥10)
Display Mode
TN, Normally White, Transmissive
Best View on
6 o'clock
Response(ms)
35 (Typ.)(Tr+Td)
Color Performance :
White Coordinate
Wx:0.313; Wy:0.329
Display Colors
262K/16.2M (6-bit / 6-bit + FRC)
Color Temperature
6485K
White Uniformity
1.33 (Max.)(5 points) 370 Cd/M² 12.1" LQ121K1LG11 Hard Coating Sharp LCD Panel 0
1931 Color Gamlt :
NTSC Ratio
50%
sRGB
69% coverage
Adobe RGB
52% coverage
DCI-P3
52% coverage
Rec.2020
37% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
