Flat Rectangle G104XVN01.0 10.4" Auo Display Panel

Flat Rectangle G104XVN01.0 10.4" Auo Display Panel
Flat Rectangle G104XVN01.0 10.4" Auo Display Panel Flat Rectangle G104XVN01.0 10.4" Auo Display Panel

Large Image :  Flat Rectangle G104XVN01.0 10.4" Auo Display Panel

Product Details:
Place of Origin: taiwan
Brand Name: AUO
Model Number: G104XVN01.0
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: pls contact us
Packaging Details: Standard Packaging
Delivery Time: 5-8 work days
Payment Terms: T/T ,Western Union,PAYPAL,BANK TRANSFER
Supply Ability: 1000

Flat Rectangle G104XVN01.0 10.4" Auo Display Panel

Description
Brand: AUO Model: G104XVN01.0
Diagonal Size: 10.4 Inch Type: A-Si TFT-LCD, LCM
Pixel Format: 1024(RGB)×768 [XGA] 123PPI Configuration: RGB Vertical Stripe
Active Area: 210.4(H)×157.8(V) Mm Touch Pane: Without
High Light:

10.4" auo display panel

,

G104XVN01.0

,

Flat Rectangle auo display panel

Flat Rectangle G104XVN01.0 10.4" Auo Display Panel





Description Of AUO LCD Panel

G104XVN01.0 supports display 1024(RGB)×768 (XGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 210.4(W)×157.8(H) mm, outline size of 238.6(W)×175.8(H)×7(D) mm,

viewing area size of 215.4(W)×161.8(H) mm, with surface treament of Antiglare, Hard coating (3H),





AUO G104XVN01.0 Mechanical Details

Pixel Features :
Resolution
1024(RGB)×768, XGA
Dot Pitch(mm)
0.0685×0.2055 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.2055×0.2055 (H×V) [123PPI]
Mechanical Size :
Active Area(mm)
210.4(H) × 157.8(V)
Bezel Area(mm)
215.4(H) × 161.8(V)
Outline Dim.(mm)
238.6(H) × 175.8(V)
Depth(mm)
6.5±0.5
Outline Features :
Form Style
Flat Rectangle
Shape Style
-
Aspect Ratio
4:3 (H:V)
Orientation
Landscape type
Mounting :
Face mounting holes (4-Φ2.8) on left, right bezel
Other Spec :
Weight
295g (Typ.)
Treatment
Antiglare, Hard coating (3H


AUO G104XVN01.0 Optical Details

Basic Information :
Luminance(cd/m²)
470(Typ.)
Contrast Ratio
3000:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
AMVA3, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
20/10 (Typ.)(Tr/Td)
Color Performance :
White Coordinate
Wx:0.313; Wy:0.329
Display Colors
262K/16.2M (6-bit / 6-bit + FRC)
Color Temperature
6485K
White Uniformity
1.25/1.33 (Typ./Max.)(5 points) Flat Rectangle G104XVN01.0 10.4" Auo Display Panel 0
1931 Color Gamlt :
NTSC Ratio
60%
sRGB
84% coverage
Adobe RGB
63% coverage
DCI-P3
63% coverage
Rec.2020
45% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)




Application Of AUO  G104XVN01.0
Industrial Control Equipment: remote control, punched-card machine..
