Product Details:
|
| Size: | 15.6 Inch | Resolution: | 400 |
|---|---|---|---|
| C/R: | 900:1 | View Angle: | 80/80/80/80 |
| Colors: | 262K/16.7M | Backlight: | WLED |
| Interface: | Without | Designed For: | Industrial |
| High Light: | nec lcd touch screen,nec tft lcd |
||
1. NLT NL13676AC25-05D Optical Details
| Pixel Features : |
Pixel Format:1366(RGB)×768, WXGA
Dot Pitch:0.084×0.252 mm (H×V)
Configuration:RGB Vertical Stripe
Pixel Pitch:0.252×0.252 mm (H×V)
|
|---|---|
| Mechanical Size : |
Display Area:344.232×193.536 mm (H×V)
Bezel Area:347.5×196.8 mm (H×V)
Outline Dim.:363.8×215.9 mm (H×V)
Outline Depth:10.33 (Typ.) mm
|
| Outline Features : |
Form Factor:Flat Rectangle
Orientation:Landscape type
Aspect Ratio:16:9 (H:V)
Shape Style:-
|
| Holes & Brackets : |
Side mounting holes (4-M3) on left, right bezel
|
| Other Features : |
Weight:800/880g (Typ./Max.)
Surface:Antiglare, Hard coating (3H)
|
2. NLT NL13676AC25-05D Mechanical Details
| Basic Information : |
Brightness:400 cd/m² (Typ.)
Contrast Ratio:900:1 (Typ.) (Transmissive)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Optical Mode:TN, Normally White, Transmissive
Viewing Direction:6 o'clock
Response Time:3/15 (Typ.)(Tr/Td) ms
|
|---|---|
| Color Performance : |
Chromaticity:Wx:0.313; Wy:0.329
Color Numbers:262K/16.7M (6-bit / 6-bit + Hi-FRC)
Color Temperature:6485K
Uniformity:1.25/1.40 (Typ./Max.)(9 points)
|
| 1931 Color Gamlt : |
NTSC Ratio:62%
sRGB:80% coverage
Adobe RGB:62% coverage
DCI-P3:65% coverage
Rec.2020:47% coverage
Remarks:sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
|
3. NLT NL13676AC25-05D Lightting Details
| Back-light Features : |
Lamp Type
WLED
Amount
-
Life Time
50K(Typ.) (Hours)
Replacement
Replaceable
Lamp Shape
-
Position
Edge light type
|
|---|---|
| Interface Features : |
Type
Connector
Position
-
Lamp Driver
With LED Driver
|
| Interface Detail : |
Brand
Model
Pin Pitch
Pins
Amount
Configuration
STM
MSB24038P6
1.25 mm
6 pins
1 pcs
|
| Driver Electrical : |
Voltage Input
12.0V (Typ.)
Current Input
660mA (Typ.)
Consumption
7.92W (Typ.)
|
