Product Details:
|
| Brand: | AUO | Size: | 10.1 Inch |
|---|---|---|---|
| Resolution: | 1600×2560 | Brightness: | 400 |
| C/R: | 800:1 | View Angle: | 85/85/85/85 |
| Panel Type: | A-Si TFT-LCD, LCM | Pixel Format: | RGB Vertical Stripe |
| Display Mode: | AHVA, Normally Black, Transmissive | Touch Screen: | Without |
| Lamp Type: | WLED , 15K Hours , Without Driver | ||
| High Light: | auo lcd screen,auo lcd display |
||
1.AUO G101QAN01.1 Mechanical Details
| Pixel Features : |
Pixel Format:1600(RGB)×2560, WQXGA
Dot Pitch:0.0282×0.0846 mm (H×V)
Configuration:RGB Vertical Stripe
Pixel Pitch:0.0846×0.0846 mm (H×V)
|
|---|---|
| Mechanical Size : |
Display Area:135.36×216.576 mm (H×V)
Bezel Area:-
|
| Outline Features : |
Form Factor:Flat Rectangle
Orientation:Portrait type
Aspect Ratio:10:16 (H:V)
Shape Style:-
|
2.AUO G101QAN01.1 Optical Details
| Basic Information : |
Brightness:400 cd/m² (Typ.)
Contrast Ratio:800:1 (Typ.) (Transmissive)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Optical Mode:AHVA, Normally Black, Transmissive
Viewing Direction:Symmetry
Response Time:25 (Typ.)(Tr+Td) ms
|
|---|---|
| Color Performance : |
Chromaticity:Wx:0.300; Wy:0.320
Color Numbers:16.7M (8-bit)
Color Temperature:7351K
Uniformity:1.25 (Max.)(5 points)
|
3.AUO G101QAN01.1 Backlight Details
| Back-light Features : |
Lamp Type:WLED
Amount:-
Life Time:15K(Min.) (Hours)
Replacement:-
Lamp Shape:-
Position:Edge light type
|
|---|---|
| Interface Features : |
Type
Included in panel signal interface
Position
-
Lamp Driver
No
|
