Product Details:
|
| Size: | 10.1 Inch | Resolution: | 1024×600 |
|---|---|---|---|
| Brightness: | 300 | C/R: | 500:1 |
| View Angle: | 70/70/60/60 | Colors: | 262K/16.7M |
| Storage Temp: | -30 ~ 70 °C | Operating Temp: | -10 ~ 60 °C |
| Used For: | Industrial | Touchscreen: | Without |
| High Light: | auo display panel,auo lcd screen |
||
1.AUO G101STN01.A Mechanical Details
| Pixel Features : |
Pixel Format:1024(RGB)×600, WSVGA
Dot Pitch:0.0725×0.2088 mm (H×V)
Configuration:RGB Vertical Stripe
Pixel Pitch:0.2175×0.2088 mm (H×V)
|
|---|---|
| Mechanical Size : |
Display Area:222.72×125.28 mm (H×V)
Bezel Area:226.34×128.1 mm (H×V)
Outline Dim.:235×143 mm (H×V)
Outline Depth:4.9/6.64 (Typ./Max.) mm
|
| Outline Features : |
Form Factor:Flat Rectangle
Orientation:Landscape type
Aspect Ratio:16:9 (H:V)
Shape Style:-
|
| Holes & Brackets : |
Side mounting holes (4-M2) on left, right bezel
|
| Other Features : |
Weight:184.5g (Typ.)
Surface:Antiglare, Hard coating (3H)
|
2.AUO G101STN01.A Optical Details
| Basic Information : |
Brightness:300 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (Transmissive)
Viewing Angle:70/70/60/60 (Typ.)(CR≥10)
Optical Mode:TN, Normally White, Transmissive
Viewing Direction:-
Response Time:7/9 (Typ.)(Tr/Td) ms
|
|---|---|
| Color Performance : |
Chromaticity:Wx:0.313; Wy:0.329
Color Numbers:262K/16.7M (6-bit / 6-bit + Hi-FRC)
Color Temperature:6485K
Uniformity:1.25 (Max.)(5 points)
|
| 1931 Color Gamlt : |
NTSC Ratio
46%
sRGB
64% coverage
Adobe RGB
48% coverage
DCI-P3
47% coverage
Rec.2020
34% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
|
3.AUO G101STN01.A Backlight Details
| Back-light Features : |
Lamp Type
WLED
Amount
-
Life Time
20K(Min.) (Hours)
Replacement
-
Lamp Shape
-
Position
Edge light type
|
|---|---|
| Lamp Electrical : |
Voltage Input
12.8/14.4V (Typ./Max.)
Current Input
30mA (Typ.)
|
| Interface Features : |
Type
Included in panel signal interface
Position
-
Lamp Driver
With LED Driver
|
| Driver Electrical : |
Voltage Input
4.0/5.0/7.0V (Min./Typ./Max.)
Current Input
415/520mA (Typ./Max.)
Consumption
2.6W (Max.)
|
