Product Details:
|
| Size: | 5.7 Inch | Resolution: | 320×240 |
|---|---|---|---|
| Brightness: | 800 | C/R: | 800:1 |
| View Angle: | 80/80/70/70 | Best View On: | 12 O'clock |
| Response Time: | 15/10 (Typ.)(Tr/Td) | Display Colors: | 262K 50% NTSC |
| Weight: | 150/165g (Typ./Max.) | Environment: | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C |
| High Light: | auo lcd screen,auo lcd display |
||
| Pixel Features : | Pixel Format | 320(RGB)×240 [QVGA] | Dot Pitch | 0.120×0.360 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.360×0.360 mm (H×V) | |
| Mechanical Size : | Display Area | 115.2×86.4 mm (H×V) | Bezel Area | 118.2×89.4 mm (H×V) |
| Outline Dim. | 144×104.6 mm (H×V) | Outline Depth | 12.3/12.8 (Typ./Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 4:3 (H:V) | Shape Style | - | |
| Holes & Brackets : | Rear mounting holes (4-Φ2.6) | |||
| Other Features : | Weight | 150/165g (Typ./Max.) | Surface | Antiglare, Hard coating (3H) |
2.AUO G057QN01 V2 Optical Details
| Basic Information : | Brightness | 800 cd/m² (Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 80/80/70/70 (Typ.)(CR≥10) | Optical Mode | TN, Normally White, Transmissive | |
| Viewing Direction | 12 o'clock | Response Time | 15/10 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Color Numbers | 262K (6-bit) |
| Color Temperature | 6485K | White Uniformity | 1.30 (Max.)(5 points) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmittance | - |
3.AUO G057QN01 V2 Backlight Details
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | 50K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | Replaceable | Amount | - | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | 25.6/29.2V (Typ./Max.) | Current Input | 100mA (Typ.) | ||
| Consumption | 2.56/2.92W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | Lamp Driver | With LED Driver |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JST | SM06B-SRKS-G-TB | 1.0 mm | 6 pins | 1 pcs | ||
| Driver Electrical : | Voltage Input | 9.0/12.0/20.0V (Min./Typ./Max.) | Current Input | 0.24/0.29A (Typ./Max.) | ||
| Consumption | 2.88/3.48W (Typ./Max.) | |||||
4.AUO G057QN01 V2 Interface Details
| Signal Systerm : | CMOS (1 ch, 6-bit) | Logic Voltage | 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 3.3V (Typ.) | Current Input | 115/130mA (Typ./Max.) | ||
| Consumption | 0.46/0.51W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| STARCONN | 089H33-000100-G2-R | 0.5 mm | 33 pins | 1 pcs | DRGB-33P1C6B-010A | |
5.Service
6.FAQ
Q1:What's the quality of your LCD Panel?
A:Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc. We are available to meet your different requirements.
Q2:What is your return and refund policy?
A:We provide you excellent after-sales services, and promise you 12-month warranty after shipping to assure you a stable performance.
Q3:How long is the lead time?
A:The lead time is about 2-3 working days after receipt of payment.
Q4:Do you accept sample order?
A:Yes,sample order is welcome.
Q5:How can I get the quotation?
A:Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
