Product Details:
|
| Size: | 4.3 Inch | Resolution: | 480*720 |
|---|---|---|---|
| Viewing Angle: | 65/65/50/55 (Typ.)(CR≥10) | Brightness: | 450 Cd/m² (Typ.) |
| Best View On: | 6 O'clock | Display Colors: | 16.7M 50% NTSC |
| Panel Weight: | 68.0g (Max.) | Contrast Ratio: | 400:1 (Typ.) (TM) |
| Touch Screen: | Without | Response Time: | 15/20 (Typ.)(Tr/Td) |
| High Light: | auo lcd screen,auo lcd display |
||
1.General Description.
G043FW01 V0 is designed for Parchinko applications with WQVGA (480*RGB*272) resolution and 16.7M colors (RGB 8-bits) .
It is composed of a TFT-LCD pannel,driver ICs and backlight unit.
G043FW01 V0 offers TTL interface for display signal input.
2.AUO G043FW01 V0 Optical Details
| Basic Information : | Luminance | 450 cd/m² (Typ.) | Contrast Ratio | 400 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | 6 o'clock | Response Speed | 15/20 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 65/65/50/55 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.320 | Support Color | 16.7M (8-bit) |
| Color Temperature | 6737K | White Uniformity | 1.33/1.43 (Typ./Max.)(9 points) |
3.AUO G043FW01 V0 Mechanical Details
| Pixel Features : |
Resolution:480(RGB)×272, WQVGA
Dot Pitch(mm):0.066×0.198 (H×V)
Pixel Format:RGB Vertical Stripe
Pixel Pitch(mm):0.198×0.198 (H×V)
|
|---|---|
| Mechanical Size : |
Active Area(mm):95.04(H) × 53.856(V)
Bezel Area(mm):100.8(H) × 58.71(V)
Outline Dim.(mm):105.7(H) × 67.4(V)
Depth(mm):4.19 (Typ.)
|
| Outline Features : |
Form Style:Flat Rectangle
Shape Style:-
Aspect Ratio:16:9 (H:V)
Orientation:Landscape type
|
| Other Spec : |
Weight:68.0g (Max.)
Treatment:Antiglare, Hard coating (3H)
|
4.AUO G043FW01 V0 Interface Detail
| Signal Electrical : |
Voltage Supply:3.3/3.3V (Typ.)(VDD/VDDIO)
Current Supply:25/20mA (Typ.)(IDD/IDDIO)
Consumption:0.1/0.15W (Typ./Max.)
|
|---|---|
| Signal Type : |
Parallel RGB (1 ch, 8-bit)
Logic Voltage:0≤VIL≤0.3VDDIO; 0.7VDDIO≤VIH≤VDDIO
|
| Interface Features : |
Type:FPC
|
| Pin Configuration | BLE-2PINS-AC |
5.Service
6.FAQ
Q1:What's the quality of your LCD Panel?
A:Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc. We are available to meet your different requirements.
Q2:What is your return and refund policy?
A:We provide you excellent after-sales services, and promise you 12-month warranty after shipping to assure you a stable performance.
Q3:How long is the lead time?
A:The lead time is about 2-3 working days after receipt of payment.
Q4:Do you accept sample order?
A:Yes,sample order is welcome.
Q5:How can I get the quotation?
A:Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
