60Hz Vehicle LCD Display AUO New Original C035QVN01.0 3.5 Inch LCM 240×320

60Hz Vehicle LCD Display AUO New Original C035QVN01.0 3.5 Inch LCM 240×320
60Hz Vehicle LCD Display AUO New Original C035QVN01.0 3.5 Inch LCM 240×320

Large Image :  60Hz Vehicle LCD Display AUO New Original C035QVN01.0 3.5 Inch LCM 240×320

Product Details:
Place of Origin: Japan
Brand Name: auo LCD
Certification: ISO9001
Model Number: C035QVN01.0
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD
Packaging Details: Standard packing
Delivery Time: 1-2days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,HKIN ESCROW .....
Supply Ability: 500PCS/DAY

60Hz Vehicle LCD Display AUO New Original C035QVN01.0 3.5 Inch LCM 240×320

Description
Panel Model: C035QVN01.0 Panel Brand: AUO
Size: 3.5 Inch Panel Type: A-Si TFT-LCD
Active Area: 53.28×71.04 Mm Outline: 69.22×87.2×21 Mm
Surface: Antiglare Contrast Ratio: 1000:1 (Min.)
High Light:

car lcd display

,

vehicle lcd display

AUO new and original C035QVN01.0 3.5 inch LCM 240×320 450 1000:1 for Automotive Display



C035QVN01.0 Information



Panel Model C035QVN01.0
Panel Brand AUO
Descrition a-Si TFT-LCD ,3.5 inch, 240×320
Panel Type a-Si TFT-LCD
Display Mode AMVA, Normally Black, Transmissive
Active Area 53.28×71.04 mm
Outline 69.22×87.2×21 mm
Surface Antiglare
Contrast Ratio 1000:1 (Min.)
Display Colors 262K (6-bit) , CIE1931 70%
Response Time 10/25 (Typ.)(Tr/Td)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency 60Hz
Lamp Type 2S2P WLED Without Driver
Signal Interface Parallel RGB (1 ch, 6-bit) , 50 pins
Input Voltage 3.3V (Typ.)



C035QVN01.0 Basic Information

Panel Model C035QVN01.0
Panel Brand AUO
Descrition a-Si TFT-LCD ,3.5 inch, 240×320
Panel Type a-Si TFT-LCD
Operating Temperature -30 ~ 85 °C
Storage Temperature -40 ~ 95 °C



C035QVN01.0 Optical Features

Display Mode AMVA, Normally Black, Transmissive
Brightness 450 cd/m² (Typ.)
Contrast Ratio 1000 : 1 (Min.) (Transmissive)
Display Color 262K (6-bit)
Color Gamut 70% NTSC (CIE1931)
Response Time 10/25 (Typ.)(Tr/Td)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction Symmetry
White color Chromaticity Wx:0.290; Wy:0.320
White Variation 1.25 (Max.)(9 points)
Sunlight Readable N



Outline : 358.5×296.5×15.8 mm
Surface : Antiglare, Hard coating (3H)
Brightness : 380 cd/m² (Typ.)
Contrast Ratio : 1000:1 (Typ.)
Display Colors : 16.7M (6-bit + Hi-FRC) , CIE1931 72%
Response Time : 3.5/1.5 (Typ.)(Tr/Td)
Viewing Angle : 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)
