Product Details:
|
| Panel Model: | A036QN02 V0 | Panel Brand: | AUO |
|---|---|---|---|
| Size: | 3.6 Inch | Panel Type: | A-Si TFT-LCD |
| Display Mode: | Normally White | Active Area: | 72.96×54.72 Mm |
| Surface: | Antiglare | Display Colors: | 16.7M (8-bit) |
| High Light: | car lcd display,car lcd panel |
||
A036QN02 V0 AUO 3.6 inch LCM 320×240 250 300:1 for MP4 PMP
A036QN02 V0 Information
| Panel Model | A036QN02 V0 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,3.6 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 72.96×54.72 mm |
| Outline | 84.55×65.5 mm |
| Surface | Antiglare |
| Contrast Ratio | |
| Display Colors | 16.7M (8-bit) |
| Response Time | 30/60 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/40/60 (Typ.)(CR≥10) (L/R/U/D) |
| Lamp Type | 4S1P WLED Without Driver |
| Signal Interface | Serial RGB (8-bit) + SPI, CCIR656 , 40 pins |
| Input Voltage | 3.3/5.25/12.5/-12.5V (Typ.)(VCC/AVDD/VGH/VGL) |
| Panel Model | A036QN02 V0 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,3.6 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Model Alias | A036QN02 V.0 |
| Operating Temperature | 0 ~ 60 °C |
| Storage Temperature | -25 ~ 80 °C |
| Dot Resolution | 320(RGB)×240 (QVGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 111 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.076×0.228 mm (H×V) |
| Pixel Pitch | 0.228×0.228 mm (H×V) |
| Surface | Antiglare |
| Active Area | 72.96×54.72 mm (H×V) |
| Bezel Area | 75.56×57.32 mm (H×V) |
| Outline Dimension | 84.55×65.5 mm (H×V) |
| Outline Depth | 3.22 (Typ.) mm |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
Our Advantage :
>>Quality Guarantee:
Our LCD Panels are 100% original and brand new!
Warranty : 12 months
You can enjoy the real panels directly from the LCD panel brand distributor.
>>Packing Guarantee:
All the products are in original package from original factory directly, and all the LCD panel packages with labels and serial number!
>>Delivery Guarantee:
We have international logistic center in HK, so we can arrange fastest and most convenient delivery for you!
>>After-Sale service
We have many years good experience on display solution.
Any question, we will reply you within 12 hours.
Excellent service on before-sale, on-sale and after-sale
1. We provide one year warranty, will provide the after-sale service for you if any quality problems.
2.Your inquiry related to our products or prices will be replied in 24 hours.
3. We will track the shipping status time by time so that buyer can receive our goods in time and safely.
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| H497TLB01.4 | AUO | 5.0" | 720×1280 |
| H500TLB01.0 | AUO | 5.0" | 720×1280 |
| X546DLB01.0 | AUO | 5.5" | 1080×1920 |
| H429ALN01 V0 | AUO | 4.3" | 540×960 |
| H163QLN01.1 | AUO | 1.63" | 320×320 |
