Product Details:
|
| Panel Brand: | AUO | Panel Size: | 3.5 Inch |
|---|---|---|---|
| Display Colors: | 16.7M | Frequency: | 60Hz |
| Panel Type: | LTPS TFT-LCD, LCM | Surface: | Glare (Haze 0%) |
| Touch Screen: | Without | ||
| High Light: | car lcd panel,vehicle lcd display |
||
AUO A035VL01 V3 3.5 inch LCM 800×480 Brightness 315 800:1
A035VL01 V3 Information
| Panel Model | A035VL01 V3 |
|---|---|
| Panel Brand | AUO |
| Descrition | LTPS TFT-LCD ,3.5 inch, 800×480 |
| Panel Type | LTPS TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 75.6×45.36 mm |
| Outline | 86.1×51.66 mm |
| Surface | Glare (Haze 0%) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 15/30 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLED Without Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit) + SPI , 70 pins |
| Input Voltage | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| Panel Model | A035VL01 V3 |
|---|---|
| Panel Brand | AUO |
| Descrition | LTPS TFT-LCD ,3.5 inch, 800×480 |
| Panel Type | LTPS TFT-LCD |
| Model Alias | A035VL01 V.3 |
| Operating Temperature | -10 ~ 60 °C |
| Storage Temperature | -25 ~ 70 °C |
| Display Mode | TN, Normally White, Transmissive |
|---|---|
| Brightness | 315 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (Transmissive) |
| Display Color | 16.7M (8-bit) |
| Response Time | 15/30 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| White color Chromaticity | Wx:0.310; Wy:0.330 |
| White Variation | 1.33/1.43 (Typ./Max.)(9 points) |
| Sunlight Readable | N |
Company Strength:
1>ISO9001 certificated.
2> Competitive Price and Short Lead-time
3> Professional Team with Rich Experiences in LCD Screen International trade.
4> Small MOQ Support & Fast Response to Customers
5> Long Product Life Time
6> Each LCD will be tested pcs by pcs before shipment to guarantee the quality.
7> We are distributor for the hard-to-find LCD Screen Panels, contained but not limited to Medical LCD Panel, Aerospace LCD Display, Gaming LCD Screen, Military LCD Replacements, Kiosk LCD Panels, Transportation LCD Panels.
8> The LCD brands we can provide to you contained but not limited to Samsung, LG, Sharp, AUO, Tianma, Chimei, Hannstar, Innolux, BOE and more.
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk
| Panel Model | Brand | Size | Resolution |
| X546DLT01 | AUO | 5.5" | 1080×1920 |
| X163QLN01 | AUO | 1.63" | 320×320 |
| H499TLB01 V0 | AUO | 5.0" | 720×1280 |
| H020HD01 V0 | AUO | 2.0" | 176×220 |
| A020AE01 V0 | AUO | 2.0" | 172×72 |
| A060SE03 V0 | AUO | 6.0" | 600×800 |
| A060XE01 V1 | AUO | 6.0" | 768×1024 |
| A060SE02 V8 | AUO | 6.0" | 800×600 |
Why do you choose us?
• Quick response to clients' enquiries within 24hrs.
• More than 6-year experience in LCD screen field and professional team communication team.
•Value quality and long-term cooperation to reach win-win relationship.
| Panel Size : | 15.6 inch |
| Dot Resolution : | 1366(RGB)×768 (WXGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 100 PPI |
| Aspect Ratio : | 16:9 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.084×0.252 mm (H×V) |
| Pixel Pitch : | 0.252×0.252 mm (H×V) |
| Weight : | 1.25/1.35Kgs (Typ./Max.) |
| Surface : | Antiglare, Hard coating (3H) |
| Active Area : | 344.232×193.536 mm (H×V) |
| Bezel Area : | 347.54×196.83 mm (H×V) |
| Outline Dimension : | 363.8×215.9 mm (H×V) |
| Outline Depth : | 16.85±0.5 mm |
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
