Product Details:
|
| Panel Brand: | AUO | Panel Size: | 3.5 Inch |
|---|---|---|---|
| Best View On: | 6 O'clock | Frequency: | 60Hz |
| Panel Weight: | 40.0g | Input Voltage: | 3.3V |
| Panel Type: | A-Si TFT-LCD | Pixel Format: | RGB Vertical Stripe |
| High Light: | car lcd display,vehicle lcd display |
||
New and original A035QN02 V4 AUO 3.5 inch LCM 320×240 350 LCD Display for Digital Still Camera
A035QN02 V4 Information
| Panel Model | A035QN02 V4 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,3.5 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 70.08×52.56 mm |
| Outline | 76.9×63.9×4.27 mm |
| Surface | Hard coating (3H) |
| Contrast Ratio | 300:1 (Typ.) |
| Display Colors | 262K (6-bit) , CIE1931 60% |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/50/55 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S1P WLED Without Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit) + SPI , 54 pins |
| Input Voltage | 3.3V (Typ.)(VCC) |
| Panel Model | A035QN02 V4 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,3.5 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Model Alias | A035QN02 V.4 |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 85 °C |
| Remarks | 3 in 1 FPC, FPC length 37mm |
| Display Mode | TN, Normally White, Transmissive |
|---|---|
| Brightness | 350 cd/m² (Typ.) |
| Contrast Ratio | 300 : 1 (Typ.) (Transmissive) |
| Display Color | 262K (6-bit) |
| Color Gamut | 60% NTSC (CIE1931) |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/50/55 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction | 6 o'clock |
| White color Chromaticity | Wx:0.310; Wy:0.330 |
| Sunlight Readable | N |
