Product Details:
|
| Panel Brand: | NEC | Panel Size: | 8.4 Inch |
|---|---|---|---|
| Frequency: | 60Hz | Input Voltage: | 3.3V (Typ.) |
| Panel Type: | A-Si TFT-LCD, LCM | Pixel Format: | RGB Vertical Stripe |
| Display Mode: | TN, Normally White | Touch Screen: | Without |
| High Light: | auo display panel,auo lcd screen |
||
| Panel Model | NL6448BC26-27C |
|---|---|
| Panel Brand | NEC |
| Descrition | a-Si TFT-LCD ,8.4 inch, 640×480 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 170.88×128.16 mm |
| Outline | 200×152 mm |
| Surface | Clear, Hard coating (2H), Antireflection |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC) , CIE1931 40% |
| Response Time | 3/15 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 strings WLED Without Driver |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins |
| Input Voltage | 3.3V (Typ.) |
| Panel Model | NL6448BC26-27C |
|---|---|
| Panel Brand | NEC |
| Descrition | a-Si TFT-LCD ,8.4 inch, 640×480 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -30 ~ 80 °C |
| Storage Temperature | -30 ~ 80 °C |
| Vibration Resistance | 2.0G (19.6 m/s²) |
| Remarks | ST-NLT, ColorXcell |
| Dot Resolution | 640(RGB)×480 (VGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 95 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.089×0.267 mm (H×V) |
| Pixel Pitch | 0.267×0.267 mm (H×V) |
| Weight | 260/280g (Typ./Max.) |
| Surface | Clear, Hard coating (2H), Antireflection |
| Active Area | 170.88×128.16 mm (H×V) |
| Bezel Area | 174.0×131.4 mm (H×V) |
| Outline Dimension | 200×152 mm (H×V) |
| Outline Depth | 8.2±0.5 mm |
| Holes & Brackets | Face mounting holes (4-Φ2.8) |
| Vertical Frequency | 60Hz |
|---|---|
| Reverse Scan | Yes (180°) |
| Total Power Consumption | 5.0W (Typ.) |
Packaging & Delivery
Packaging: Safety Package For all of our LCD Screen Panel Replacements.
Details: 1. Antistatic bag
2. Layers of cartons
3. Foam Box
4. Carton Box.
