Product Details:
|
| Panel Brand: | AUO | Panel Size: | 14.0 Inch |
|---|---|---|---|
| Brightness: | 400 Cd/m² | Best View On: | Symmetry |
| Frequency: | 60Hz | Panel Weight: | TBD |
| Signal Interface: | EDP | Pixel Format: | RGB Vertical Stripe |
| High Light: | auo display panel,auo lcd display |
||
| Pixel Features : |
Pixel Format
1920(RGB)×1080, FHD
Dot Pitch
0.054×0.161 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.161×0.161 mm (H×V)
|
|---|---|
| Mechanical Size : |
Display Area
309.14×173.89 mm (H×V)
Bezel Area
-
Outline Dim.
319×190.76 mm (H×V)
Outline Depth
4.9/8.3 (Typ./Max.) mm
|
| Outline Features : |
Form Factor
Flat Rectangle Display
Orientation
Landscape type
Aspect Ratio
16:9 (H:V)
Shape Style
-
|
| Holes & Brackets : |
Without
|
| Other Features : |
Weight
TBD
Surface
Glare (Haze 0%), Hard coating (3H)
|
| Basic Information : |
Brightness
400 cd/m² (Typ.)
Contrast Ratio
800:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Optical Mode
AHVA, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
15/10 (Typ.)(Tr/Td) ms
|
|---|---|
| Color Performance : |
Chromaticity
Wx:0.313; Wy:0.329
Color Numbers
16.2M (6-bit + FRC)
Color Gamut
72% NTSC (CIE1931)
Uniformity
1.33 (Max.)(5 points)
|
| Back-light Features : |
Lamp Type
WLED
Amount
-
Life Time
50K(Min.) (Hours)
Replacement
-
Lamp Shape
-
Position
Edge light type
|
|---|---|
| Interface Features : |
Type
Included in panel signal interface
Position
-
Lamp Driver
With LED Driver
|
| Driver Electrical : |
Voltage Input
5.0/12.0/21.0V (Min./Typ./Max.)
Current Input
462mA (Typ.)
Consumption
5.54/6.1W (Typ./Max.)
|
Up to now, over hundreds of aerospace, power management, network, communications, instrumentation and consumer electronics, etc are benefiting from our service and LCD screen panels.
We can do for you:
FAQ
Q1: What's price?
A1: We provide reasonable price and recommend suitable batteries to our customers.
Q2: What's delivery time?
A2: The delivery time is normally 1-3 working days after payment.
Q3: What's the payment?
A3: We accept T/T, Western Union, MoneyGram, Paypal
Q4: Can we visit your factory?
A4: Warmly welcome. Once we have your schedule, we will arrange professional sales team to follow up your case.
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| X139BLB01.0 | AUO | 1.39" | 400×400 |
| H381DLN01.0 | AUO | 3.8" | 1080×1200 |
| H497TLB01.4 | AUO | 5.0" | 720×1280 |
| H163QLN01.0 | AUO | 1.63" | 320×320 |
| H139BLN01.2 | AUO | 1.39" | 400×400 |
| H500TLB01.0 | AUO | 5.0" | 720×1280 |
| X546DLB01.0 | AUO | 5.5" | 1080×1920 |
| H546DLB01.1 | AUO | 5.5" | 1080×1920 |
Pls contact to us for more stock information
