27 Inch AUO LCD Screen G270ZAN01.1 LCM 3840×2160 New / Original Condition

27 Inch AUO LCD Screen G270ZAN01.1 LCM 3840×2160 New / Original Condition

27 Inch AUO LCD Screen G270ZAN01.1 LCM 3840×2160 New / Original Condition

Product Details:

Place of Origin: KOREA
Brand Name: AUO
Certification: ISO9001
Model Number: G270ZAN01.1

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: Western Union, T/T, MoneyGram, T/T
Supply Ability: 500PCS/DAY
Contact Now
Detailed Product Description
Panel Type: A-Si TFT-LCD , LCM Panel Size: 27.0 Inch
Resolution: 1920(RGB)×1080 , FHD Display Mode: AMVA, Normally Black, Transmissive
Active Area: 597.6×336.15 Mm Outline: 630.6×368.2×11 Mm

New and original AUO G270ZAN01.1 27 inch LCM 3840×2160 for Industrial Application


AUO G270ZAN01.1 Mechanical Features


Panel Size : 27.0 inch
Pixel Features : Resolution Pixel Arrangement Dot Pitch (W×H) Pixel Pitch (W×H)
3840(RGB)×2160, UHD RGB Vertical Stripe 0.05175×0.15525 mm 0.15525×0.15525 mm
Mechanical Size : Active Area (W×H) Bezel Area (W×H) Outline Dimension (W×H) Outline Depth
596.16×335.14 mm 602.0×340.4 mm 630×368.2 mm 22.9 (Typ.) mm
Outline Features : Form Style Aspect Ratio Orientation Shape Style
Flat Rectangle Display 16:9 (W : H) Landscape type -
Fixation : Side mounting holes (4-M3) on left, right bezel
Other Features : Panel Cover Weight Surface
- 3.40Kgs (Typ.) Antiglare


AUO G270ZAN01.1 Optical Features

Basic Information : Brightness Operating Mode Contrast Ratio
800 cd/m² (Typ.) AHVA, Normally Black, Transmissive 1000:1 (Typ.) (Transmissive)
Viewing Angle(L/R/U/D) Viewing Direction Response Speed
89/89/89/89 (Typ.)(CR≥10) Symmetry 16 (Typ.)(Tr+Td) (ms)
Dispaly Color : Color Gamut Color Amount White color Chromaticity
90% NTSC (CIE1931) 1.07B (10-bit) Wx:0.313; Wy:0.329
Luminance Variation : 1.18/1.25 (Typ./Max.)(9 points)
Performance : 3D Type Outdoor Visibility Reflectance
- Sunlight Readable -

AUO G270ZAN01.1 Specification Source

Datasheet Referenced : File Number Version Language Issue Date
- Ver0.1 English 2017 - 4 - 5
Panelook Latest Update : 2018-03-28 13:54


Our Service

• Long lasting product cycle for continuity thru all phases of project rollouts and servicing

• Competitive price for different brands hard disk.

• Mass stock with the better price.

• Multiple options.

• Warranty service.

• Better team to provide the before-sales, on-sale and after-sale service

• Pls send us message if any hard disk needed.


We Can Do for You:

1) One-to-one service with efficient & professional support;

2) Protection of your design and all your private information;

3) We could supply different hard disk for you.

4) Quality stability, can to provide certification of products;

5) Convenient payment methods: PayPal, T/T and Western Union;

6) Speedy shipment: we could arrange the shipment within 1-3 business days.

7) Quality & Service: Our priority has always been providing our clients with great quality products and superior customer service.

8) Unbeatable Prices: We continuously strive to find ways of reducing our production costs, and passing the savings to you.


Below are our other LCD panels stock for your easy reference:


Panel Model Brand Size Resolution
T500QVN03.3 CELL AUO 50" 3840×2160
T500QVN03.0 CELL AUO 50" 3840×2160
H497DAN02.1 AUO 5.0" 1080×1920
H546DAN07.3 AUO 5.5" 1080×1920
M270HVN02.3 CELL AUO 27.0" 1920×1080
M270HVN02.2 CELL AUO 27.0" 1920×1080


We also have other industrial LCD panels, pls contact to us for the further information
