Product Details:
|
| Panel Brand: | AUO | Panel Size: | 32.0 Inch |
|---|---|---|---|
| Best View On: | Symmetry | Frequency: | 60Hz |
| Panel Weight: | 4.63±0.46Kgs | Panel Type: | A-Si TFT-LCD , LCM |
| Pixel Format: | RGB Vertical Stripe | Surface: | Antiglare |
| High Light: | auo display panel,auo lcd screen |
||
G320ZAN01.0 AUO 32 inch LCM 3840×2160 Brightness 700 for Outdoor High Brightness
| Panel Size : | 32.0 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 3840(RGB)×2160, UHD | RGB Vertical Stripe | 0.0615×0.1845 mm | 0.1845×0.1845 mm | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 708.48×398.52 mm | 714.48×404.52 mm | 727.3×424.5 mm | 20.48±0.5 mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle Display | 16:9 (W : H) | Landscape type | - | |
| Fixation : | Rear mounting holes | |||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 4.63±0.46Kgs | Antiglare | ||
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 700 cd/m² (Typ.) | AHVA, Normally Black, Transmissive | 1350:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 89/89/89/89 (Typ.)(CR≥10) | Symmetry | 8/10 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Gamut | Color Amount | White color Chromaticity |
| 100% Adobe RGB | 1.07B (8-bit + Hi-FRC) | Wx:0.313; Wy:0.329 | |
| Luminance Variation : | 1.28 (Max.)(9 points) | ||
| Performance : | 3D Type | Outdoor Visibility | Reflectance |
| - | Sunlight Readable | - | |
Our Advantages
After-sales-service With 12 Months Warranty for our LCD panels.
Packaging & Delivery
· Delivery Lead Time :2~3 weeks
· Minimum Order :1 pcs LCD Panel
· Supply Ability :100 PCS / Per Day
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| B070EAN02.0 CELL | AUO | 7.0" | 800×1280 |
| M320QAN01.0 CELL | AUO | 32.0" | 3840×2160 |
| H546TAN02.0 | AUO | 5.5" | 720×1280 |
| H598TAN01.0 | AUO | 6.0" | 720×1280 |
| H546DAN03.3 | AUO | 5.5" | 1080×1920 |
| H497DAN02.0 | AUO | 5.0" | 1080×1920 |
| H495TAN01.1 | AUO | 5.0" | 720×1280 |
| H496TAN01.0 | AUO | 5.0" | 720×1280 |
We also have other industrial LCD panels, pls contact to us for the further information
