Product Details:
|
| Brand: | AUO | Diagonal Size: | 15.6 Inch |
|---|---|---|---|
| Model: | G156XW01 V302 | Type: | A-Si TFT-LCD, LCM |
| Configuration: | RGB Vertical Stripe | Contrast Ratio: | 500:1 |
| Operating Mode: | TN, Normally White | Touch Panel: | Without |
| High Light: | auo display panel,auo lcd screen |
||
| Pixel Features : |
Resolution
1366(RGB)×768, WXGA
Dot Pitch(mm)
0.084×0.252 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.252×0.252 (H×V)
|
|---|---|
| Mechanical Size : |
Active Area(mm)
344.232(H) × 193.536(V)
Bezel Area(mm)
347.54(H) × 196.83(V)
Outline Dim.(mm)
363.8(H) × 215.9(V)
Depth(mm)
9.3±0.5
|
| Outline Features : |
Form Style
Flat Rectangle Display
Shape Style
-
Aspect Ratio
16:9 (H:V)
Orientation
Landscape type
|
| Mounting : |
Side mounting holes (4-M3) on left, right bezel
|
| Other Spec : |
Weight
860±40g
Treatment
Antiglare, Hard coating (3H)
|
| Basic Information : |
Luminance(cd/m²)
500 (Typ.)
Contrast Ratio
500:1 (Typ.) (Transmissive)
Viewing Angle
85/85/80/80 (Typ.)(CR≥10)
Display Mode
TN, Normally White, Transmissive
Best View on
-
Response(ms)
6/2 (Typ.)(Tr/Td)
|
|---|---|
| Color Performance : |
White Coordinate
Wx:0.313; Wy:0.329
Display Colors
16.2M (6-bit + FRC)
Color Gamut
65% NTSC (CIE1931)
White Uniformity
1.33/1.43 (Typ./Max.)(9 points)
|
Delivery Quantity: 50-100 cartons shipped by DHL every week
What is our advantage?
Factory Experience: More than 6 years of experience in the agency & sourcing line of Hard-to-find LCD Screen replacements.
Supply Ability: 100 pcs Panels per day.
Supply Area: All over the word (Most of North America, South America, Europe, Japan, Korea and more.)
Warranty: 12 months.
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 16 pcs / box | 15.3 Kgs | 450×375×319 mm (L×W×H) |
FAQ
Q1: Can I place sample order first?
A1: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
Q2: How could I pay them?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: How to place the order?
A3: Please send us your purchase order by e-mail, whatsapp or Skype or you can ask us to send you a Proforma Invoice for your order.
Q4: How long can I get my order?
A4: For samples, we will finish production and ship within 1-3 working days. For bulk orders, that will base on the order quantity.
Q5: How to send us the products?
A5: We usually use DHL, UPS, FedEx to ship our LCD screen replacements to our clients.
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| A090XE01 V6 | AUO | 9.0" | 1024×768 |
| A090XE01 V5 | AUO | 9.0" | 1024×768 |
| A043SE01 V3 | AUO | 4.3" | 600×800 |
| H283QN00 V6 | AUO | 2.8" | 240×320 |
| M270DAN01.0 CELL | AUO | 27.0" | 2560×1440 |
| H644DAN01.1 | AUO | 6.5" | 1080×1920 |
| B140RTN02.0 CELL | AUO | 14.0" | 1600×900 |
| B156HW03 V0 CELL | AUO | 15.6" | 1920×1080 |
Pls contact to us for more stock information
