15 Inch AUO Display Panel , G150XTK01.1 LCM Flat Panel LCD Display 1024×768

15 Inch AUO Display Panel , G150XTK01.1 LCM	Flat Panel LCD Display 1024×768
15 Inch AUO Display Panel , G150XTK01.1 LCM	Flat Panel LCD Display 1024×768

Large Image :  15 Inch AUO Display Panel , G150XTK01.1 LCM Flat Panel LCD Display 1024×768

Product Details:
Place of Origin: KOREA
Brand Name: AUO
Certification: ISO9001
Model Number: G150XTK01.1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500PCS/DAY

15 Inch AUO Display Panel , G150XTK01.1 LCM Flat Panel LCD Display 1024×768

Description
Panel Brand: AUO Panel Size: 15.0 Inch
Panel Type: A-Si TFT-LCD, LCM Pixel Format: RGB Vertical Stripe
Surface: Antiglare Contrast Ratio: 700:1
Display Mode: TN, Normally White, Touch Screen: PCAP, On-Cell
High Light:

auo lcd screen

,

auo lcd display

New and original G150XTK01.1 AUO 15 inch LCM 1024×768 350 for Industrial Applciation



AUO G150XTK01.1 Mechanical Features

Panel Size : 15.0"
Pixel Features : Pixel Format Pixel Configuration Pixel Pitch (mm) Dot Pitch (mm)
1024(RGB)×768 [XGA] RGB Vertical Stripe 0.297×0.297 0.099×0.297
Mechanical Size : Active Area (mm) Bezel Area (mm) Outline Dimension (mm) Outline Depth (mm)
304.128(H) × 228.096(V) 307.4(H) × 231.3(V) 326.5(H) × 253.5(V) 9.5±0.5 mm
Outline Features : Form Factor Orientation Aspect Ratio Shape Style
Flat Rectangle Display Landscape type 4:3 (H:V) -
Touch Screen : Controller Touch Points Interface TP Technology
With touch controller 5 points USB PCAP, On-Cell
Mounting : Side mounting holes (4-M3) on left, right bezel
Other Detail : Weight Panel Cover Treatment
TBD - Antiglare

AUO G150XTK01.1 Backlight Features

Lamp Features: Type Position Quantity  Shape Life(Hours) Lamp Exchange
WLED Edge light type - - 70K(Typ.) No
Interface Features : Position Backlight Driver Type
- With LED Driver Included in panel signal interface
Driver Electrical : Voltage Supply Current Supply Power Consumption
12.0±1.2V 0.45A (Typ.) 5.4W (Typ.)

AUO G150XTK01.1 Specification Source

Datasheet Referenced : File Number Version Language Issue Date
- Ver0.0 English 2016 - 6 - 16
Panelook Latest Update : 2018-07-05 17:16



What is Our Advantage?

1. We are the professional supplier of the industrial LCD Screen Replacements, located in the biggest components center of the world.

2. We can provide the one-stop purchase service.

3. Our clients can grow their business by focusing on their sales, ware-housing and distribution while we take care of their China buying.

4. Client relationship and production management are the key factors that ensure successful China buying. Your account will be managed by our professional project managers.

5. Fast delivery.

6. Reasonable price.



Shipment for the LCD Display Panels:

1. Safe & Professional package for our LCD panels.

2. We can ship to you by UPS/FEDEX/DHL/TNT and so on. Other shipping terms can also be arranged according to specific requirements.

3. We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

4. All our LCD panel will be tested pcs by pcs before been shipped out.



Here comes our other LCD panels stock for your easy reference:



Panel Model Brand Size Resolution
M238DAN01.1 CELL AUO 23.8" 2560×1440
M270DAN02.0 CELL AUO 27.0" 2560×1440
H598DAN03.0 AUO 6.0" 1080×1920
H546TAN02.3 AUO 5.5" 720×1280
G173HW01 V0 CELL AUO 17.3" 1920×1080
T320HVN05.A CELL AUO 31.5" 1920×1080
B080EAN04.1 CELL AUO 8.0" 800×1280
T500HVN08.8 CELL AUO 50" 1920×1080
H546DAN01.5 AUO 5.5" 1080×1920
H546DAN08.0 AUO 5.5" 1080×1920
B080XAN03.5 AUO 7.9" 768×1024
B080XAN03.2 AUO 7.9" 768×1024
H499TAN05.0 AUO 5.0" 720×1280
