Product Details:
|
| Panel Module: | G133XTN01.1 | Screen Size: | 13.3 Inch |
|---|---|---|---|
| Color Depth: | 16.7M | Mass: | 255g |
| Refresh Rate: | 60Hz | Screen Type: | LCM, A-Si TFT-LCD |
| Arrangement: | RGB Vertical Stripe | Contrast Ratio: | 400 : 1 |
| Touchscreen: | Without | ||
| High Light: | auo display panel,auo lcd display |
||
New and original G133XTN01.1 AUO 13.3 inch LCM 1366×768 300 for Industrial Application
AUO G133XTN01.1 Mechanical Details
| Pixel Features : | Number of Pixel | 1366(RGB)×768 [WXGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.0716×0.2148 mm | Pixel Pitch(W×H) | 0.2148×0.2148 mm | |
| Physical Size : | Active Viewing | 293.42(W)×164.97(H) mm | Overall Dim. | 306.3(W)×203.7(H) mm |
| Bezel Opening | - | Overall Depth | 3.0 (Max.) mm | |
| Outline Features : | Form Shape | Flat Rectangle Display | Orientation | Landscape type |
| Aspect Ratio(W:H) | 16:9 | Shape Style | Slim (PCBA Flat, Depth ≤3.2mm) | |
| Fixation : | Face mounting holes (8 pcs) on up, down slugs | |||
| Other Detail : | Mass | 255g (Max.) | Surface | Antiglare, Hard coating (3H) |
| Basic Information : | Luminance | 300 cd/m² (Typ.) | Contrast Ratio | 400 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | - | Response Speed | 5.7/2.3 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Support Color | 16.7M (6-bit + Hi-FRC) |
| Gamut | 45% NTSC (CIE1931) | White Variation | 1.25 (Max.)(5 points) |
FAQ
Q1: Can I place sample order first?
A1: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
Q2: How could I pay them?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: How to place the order?
A3: Please send us your purchase order by e-mail, whatsapp or Skype or you can ask us to send you a Proforma Invoice for your order.
Q4: How long can I get my order?
A4: For samples, we will finish production and ship within 1-3 working days. For bulk orders, that will base on the order quantity.
Q5: How to send us the products?
A5: We usually use DHL, UPS, FedEx to ship our LCD screen replacements to our clients.
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| H497TLB01.4 | AUO | 5.0" | 720×1280 |
| H500TLB01.0 | AUO | 5.0" | 720×1280 |
| X546DLB01.0 | AUO | 5.5" | 1080×1920 |
| H429ALN01 V0 | AUO | 4.3" | 540×960 |
| H163QLN01.1 | AUO | 1.63" | 320×320 |
