Product Details:
|
| Panel Brand: | AUO | Diagonal Size: | 5.0 Inch |
|---|---|---|---|
| Model: | G050TAN01.0 | Configuration: | RGB Vertical Stripe |
| Contrast Ratio: | 1000:1 | Operating Mode: | AHVA, Normally Black |
| High Light: | auo display panel,auo lcd display |
||
| Panel Size : | 5.0 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 720(RGB)×1280, WXGA | RGB Vertical Stripe | 0.2875×0.8625 mm | 0.8625×0.8625 mm | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 62.1×110.4 mm | - | 66.7×120.3 mm | 1.65 (Typ.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle Display | 9:16 (W : H) | Portrait type | - | |
| Other Features : | Panel Cover | Weight | Surface | |
| - | 65.0 (Typ.) | Antiglare, Hard coating (3H) | ||
Our advantages in the LCD Screen market:
1.Better price
2.Fast delivery
3.Top quality
4.First class after - sales service
5.No memory effect
6.Sourcing lines & Distributors for the EOL LCD.
AUO G050TAN01.0 Optical Features
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 600 cd/m² (Typ.) | AHVA, Normally Black, Transmissive | 1000:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 80/80/80/80 (Typ.)(CR≥10) | Symmetry | 35 (Typ.)(Tr+Td) (ms) | |
| Dispaly Color : | Color Gamut | Color Amount | White color Chromaticity |
| 70% NTSC (CIE1931) | 16.7M (8-bit) | Wx:0.313; Wy:0.329 | |
| Luminance Variation : | 1.33 (Max.)(5 points) | ||
| Signal Electrical : | Current Input | Voltage Input | Consumption | |||
|---|---|---|---|---|---|---|
| - | 1.8/2.8V (Typ.)(VDD/VCI) | - | ||||
| Interface Features : | Position | Type | Interface | |||
| - | Connector | MIPI (4 data lanes) | ||||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| 5565-3078 | 1 pcs | 30 pins | ||||
FAQ
1. Q: Where can I get the price?
A:We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we'll regard your inquiry priority.
2. Q: How can I get a sample to check your quality?
A: After price confirmation, you can require for samples to check our quality.
3. Q: What about the lead time for mass production?
A: It depends on your order quantity and the season you place the order.
4. Q: What are your terms of payment?
A: We accept T/T, Western Union, MoneyGram, PayPal.
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| H020HD01 V0 | AUO | 2.0" | 176×220 |
| A020AE01 V0 | AUO | 2.0" | 172×72 |
| A060SE03 V0 | AUO | 6.0" | 600×800 |
| A060XE01 V1 | AUO | 6.0" | 768×1024 |
| A060SE02 V8 | AUO | 6.0" | 800×600 |
| A090XE02 V3 | AUO | 9.0" | 1024×768 |
| A060SE02 VC | AUO | 6.0" | 800×600 |
| A060SE02 V9 | AUO | 6.0" | 800×600 |
