Product Details:
|
| Manufacturer: | AUO | Screen Size: | 4.0 Inch |
|---|---|---|---|
| Model Name: | A040CN01 V3 | Screen Type: | LCM, A-Si TFT-LCD |
| Arrangement: | RGB Delta | Touchscreen: | Without |
| Work Mode: | TN, Normally White, | Color Depth: | Full Color |
| High Light: | auo display panel,auo lcd screen |
||
A040CN01 V3 AUO 4inch LCM 480×234 300 for video Door phone
A040CN01 V3 Information
| Panel Model | A040CN01 V3 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,4.0 inch, 480×234 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 82.11×61.77 mm |
| Outline | 95.35×77 mm |
| Surface | |
| Contrast Ratio | 150:1 (Typ.) |
| Display Colors | Full color |
| Response Time | 15/20 (Typ.)(Tr/Td) |
| Viewing Angle | 45/45/10/30 (Typ.)(CR≥10) (L/R/U/D) |
| Lamp Type | 3S2P WLED Without Driver |
| Signal Interface | TFT Specific Analog RGB , 30 pins |
| Input Voltage | 5/5/15/-9.5V (Typ.)(VCC/AVDD/VGH/VGL) |
| Panel Model | A040CN01 V3 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,4.0 inch, 480×234 |
| Panel Type | a-Si TFT-LCD |
| Model Alias | A040CN01 V.3 |
| Operating Temperature | 0 ~ 60 °C |
| Storage Temperature | -25 ~ 80 °C |
| Dot Resolution | 480×234 |
|---|---|
| Pixel Configuration | RGB Delta |
| Pixel Density | 70 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.171×0.264 mm (H×V) |
| Weight | 50±5g |
| Active Area | 82.11×61.77 mm (H×V) |
| Bezel Area | 84.41×64.07 mm (H×V) |
| Outline Dimension | 95.35×77 mm (H×V) |
