Digital Video Camera AUO LCD Panel A035QN02 VG LCM 320×240 3.5 Inch Diagonal Size

Digital Video Camera AUO LCD Panel A035QN02 VG LCM 320×240 3.5 Inch Diagonal Size
Digital Video Camera AUO LCD Panel A035QN02 VG LCM 320×240 3.5 Inch Diagonal Size

Large Image :  Digital Video Camera AUO LCD Panel A035QN02 VG LCM 320×240 3.5 Inch Diagonal Size

Product Details:
Place of Origin: KOREA
Brand Name: AUO
Certification: ISO9001
Model Number: A035QN02 VG
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500PCS/DAY

Digital Video Camera AUO LCD Panel A035QN02 VG LCM 320×240 3.5 Inch Diagonal Size

Description
Brand: AUO Diagonal Size: 3.5 Inch
Model: A035QN02 VG Type: A-Si TFT-LCD , LCM
Configuration: RGB Vertical Stripe Touch Panel: Without
High Light:

auo lcd screen

,

auo lcd display

New and original A035QN02 VG AUO 3.5 inch LCM 320×240 430 for Digital Video Camera



A035QN02 VG Information



Panel Model A035QN02 VG
Panel Brand AUO
Descrition a-Si TFT-LCD ,3.5 inch, 320×240
Panel Type a-Si TFT-LCD
Display Mode TN, Normally White, Transmissive
Active Area 70.08×52.56 mm
Outline 76.9×63.9×3.12 mm
Surface
Contrast Ratio 300:1 (Typ.)
Display Colors 262K (6-bit) , CIE1931 60%
Response Time 10/15 (Typ.)(Tr/Td)
Viewing Angle 60/60/50/55 (Typ.)(CR≥10) (L/R/U/D)
Frequency 60Hz
Lamp Type 6S1P WLED Without Driver
Signal Interface Parallel RGB (1 ch, 6-bit) + SPI , 67 pins
Input Voltage 3.3/3.3V (Typ.)(VCI/VDDIO)



A035QN02 VG Basic Information

Panel Model A035QN02 VG
Panel Brand AUO
Descrition a-Si TFT-LCD ,3.5 inch, 320×240
Panel Type a-Si TFT-LCD
Model Alias A035QN02 V.G
Operating Temperature -20 ~ 70 °C
Storage Temperature -40 ~ 80 °C
Remarks 2 in 1 FPC, FPC length 29.5mm



A035QN02 VG Optical Features

Display Mode TN, Normally White, Transmissive
Brightness 430 cd/m² (Typ.)
Contrast Ratio 300 : 1 (Typ.) (Transmissive)
Display Color 262K (6-bit)
Color Gamut 60% NTSC (CIE1931)
Response Time 10/15 (Typ.)(Tr/Td)
Viewing Angle 60/60/50/55 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction 6 o'clock
White color Chromaticity Wx:0.310; Wy:0.330
Sunlight Readable N



A035QN02 VG Backlight System

Lamp Position Edge light type
Lamp Type WLED
Lamp Amount 6S1P
Lamp Shape 1 string
Lamp Life Time 10K(Min.) (Hours)
Lamp Voltage 19.2/21.0V (Typ./Max.)
Lamp Current 20/22mA (Typ./Max.)
Interface Type Included in panel signal interface
Lamp Driver Board No
