Product Details:
|
| Panel Model: | G156XTT01.1 | Panel Size: | 15.6 Inch |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD | Display Mode: | TN, Normally White |
| Contrast Ratio: | 500:1 | Frequency: | 60Hz |
| High Light: | auo display panel,auo lcd screen |
||
G156XTT01.1 AUO 15.6 inch LCM 1366×768 350 500:1 for Industrial Application
G156XTT01.1 Information
| Panel Model | G156XTT01.1 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,15.6 inch, 1366×768 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 344.232×193.536 mm |
| Outline | 363.8×215.9×12.5 mm |
| Surface | Antiglare, Hard coating (7H) |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 16.2M (6-bit + FRC) , CIE1931 62% |
| Response Time | 6/2 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLED Embedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins |
| Input Voltage | 5.0V (Typ.) |
| Panel Model | G156XTT01.1 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,15.6 inch, 1366×768 |
| Panel Type | a-Si TFT-LCD |
| Model Alias | G156XTT01 V.1 |
| Operating Temperature | 0 ~ 60 °C |
| Storage Temperature | -20 ~ 60 °C |
G156XTT01.1 Optical Features
| Display Mode | TN, Normally White, Transmissive |
|---|---|
| Brightness | 350 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (Transmissive) |
| Display Color | 16.2M (6-bit + FRC) |
| Color Gamut | 62% NTSC (CIE1931) |
| Response Time | 6/2 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| White color Chromaticity | Wx:0.313; Wy:0.329 |
| White Variation | 1.33/1.43 (Typ./Max.)(9 points) |
| Sunlight Readable | N |
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| X139BLB01.0 | AUO | 1.39" | 400×400 |
| H381DLN01.0 | AUO | 3.8" | 1080×1200 |
| H497TLB01.4 | AUO | 5.0" | 720×1280 |
| H163QLN01.0 | AUO | 1.63" | 320×320 |
| H139BLN01.2 | AUO | 1.39" | 400×400 |
| H500TLB01.0 | AUO | 5.0" | 720×1280 |
| X546DLB01.0 | AUO | 5.5" | 1080×1920 |
| H546DLB01.1 | AUO | 5.5" | 1080×1920 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
Why do you choose us?
• Quick response to clients' enquiries within 24hrs.
• More than 6-yearexperience in LCD screen field and professional team communication team.
•Value quality and long-term cooperation to reach win-win relationship.
Packaging & Delivery
Packaging: Safety Package For all of our LCD Screen Panel Replacements.
Details: 1. Plastic Trays Inside
2. Layers of cartons
3. Fragile Sign on top.
4. Can be customized.
Details Pictures for G156XTT01.1
