Product Details:
|
| Panel Brand: | TIANMA | Size: | 3.5 Inch |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD | Display Mode: | TN, Normally White, |
| Active Area: | 70.08×52.56 Mm | Outline: | 76.9×63.9×4.2 Mm |
| Contrast Ratio: | 400:1 | Frequency: | 60Hz |
| High Light: | black and white lcd display,lcd display white screen |
||
New and original TM035KBH11-09 3.5 inch LCD display for Digital Still Camera
TM035KBH11-09 Information
| Panel Model | TM035KBH11-09 |
|---|---|
| Panel Brand | TIANMA |
| Descrition | a-Si TFT-LCD ,3.5 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 70.08×52.56 mm |
| Outline | 76.9×63.9×4.2 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Dithering) , CIE1931 50% |
| Response Time | 20 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S1P WLED Without Driver |
| Signal Interface | Digital RGB (8/24-bit) + SPI, CCIR601/656 , 54 pins |
| Input Voltage | 3.3V (Typ.) |
| Panel Model | TM035KBH11-09 |
|---|---|
| Panel Brand | TIANMA |
| Descrition | a-Si TFT-LCD ,3.5 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -20 ~ 60 °C |
| Storage Temperature | -30 ~ 70 °C |
| Remarks | 3 in 1 FPC; Down side FPC (37.00mm length) |
| Display Mode | TN, Normally White, Transmissive |
|---|---|
| Brightness | 350 cd/m² (Typ.) |
| Contrast Ratio | 400 : 1 (Typ.) (Transmissive) |
| Display Color | 16.7M (6-bit + Dithering) |
| Color Gamut | 50% NTSC (CIE1931) |
| Response Time | 20 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction | 12 o'clock |
| White color Chromaticity | Wx:0.320; Wy:0.335 |
| White Variation | 1.25/1.33 (Typ./Max.)(9 points) |
| Sunlight Readable | N |
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| TM045YYSP02 | Tianma | 4.5" | 480×854 |
| TM016XYHP01 | Tianma | 1.6" | 256×320 |
| TM050JYSP01 | Tianma | 5.0" | 720×1280 |
| TL055VGXP01 | Tianma | 5.5" | 1080×1920 |
| TM045YYHP08 | Tianma | 4.5" | 480×854 |
| TL050JGXP01 | Tianma | 5.0" | 720×1280 |
| TM050JYHP05 | Tianma | 5.0" | 720×1280 |
Product Descriptions:
Panel Size :5.7 inch
Dot Resolution : 320(RGB)×240 (QVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 70 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.120×0.360 mm (H×V)
Pixel Pitch : 0.360×0.360 mm (H×V)
Surface : Antiglare, Hard coating (3H)
Active Area : 115.2×86.4 mm (H×V)
Landscape or Portrait : Landscape type
Touch Panel : Without
Features For Tianma TM057KDH05 TFT LCD Module:
• 15000 Working Hours.
• CCFL Lamp Type.
• NEMA 4/4X/12 front bezel
• ISO9001 Compliant
• 9.0W (Typ.) Power
• Simplified installation with no studs
• 2-Year warranty
INTRODUCTION:
The ATianma TM080SV-22L03 TFT LCD Module screen monitor is a fully-integrated, off-the-shelf unit (COTS) that combines high-performance Projected Capacitive Touch Technology (PCT or PCAP); in an industrial-grade LCD flat panel, with open Frame chassis mount industrial design. The PCAP industrial multi-touch displays with HMI interface provide full range of industrial-grade units with multi-function capabilities and brilliant displays.
We also provide full list for the Tianma LCD model series. We are distributor for Commercial & Industrial LCD Panel not only for the Tianma LCD, but also the LCD panels for Samsung, LG, Sharp, Innolux, AUO, BOE and more.
