Product Details:
|
| Panel Type: | A-Si TFT-LCD | Panel Size: | 9.0 Inch |
|---|---|---|---|
| Resolution: | 1280×720 | Surface: | Antiglare |
| Contrast Ratio: | 900:1 (Typ.) | Frequency: | 60Hz |
| High Light: | industrial touch screen display,industrial lcd panel |
||
Normally Black CPT 9.0 inch CLAA090WK05XN TFT LCD Module , 800×600 resolution Outline 210.7×124.1×6.3 mm Surface Antigla
FAQ
Q1: What's price?
A1: We provide reasonable price and recommend suitable batteries to our customers.
Q2: What's delivery time?
A2: The delivery time is normally 1-3 working days after payment.
Q3: What's the payment?
A3: We accept T/T, Western Union, MoneyGram, Paypal
Q4: Can we visit your factory?
A4: Warmly welcome. Once we have your schedule, we will arrange
professional sales team to follow up your case.
Quality Control:
1. Visual Inspection
Make sure No damage, No Scratches, No dusty, No light leakage.
2. Function Inspection
Make sure all functions are 100% tested ok
CLAA090WK05XN Basic Information
| Panel Model | CLAA090WK05XN |
| Panel Brand | CPT |
| Descrition | a-Si TFT-LCD ,9.0 inch, 1280×720 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Vibration Resistance | 2.9G (28.4 m/s²) |
CLAA090WK05XN Mechanical Features
| Dot Resolution | 1280(RGB)×720 (WXGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 163 PPI |
| Aspect Ratio | 16:9 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.0518×0.1554 mm (H×V) |
| Pixel Pitch | 0.1554×0.1554 mm (H×V) |
| Weight | 250g (Typ.) |
| Surface | Antiglare |
| Active Area | 198.912×111.888 mm (H×V) |
| Bezel Area | 202.6×115.6 mm (H×V) |
| Outline Dimension | 210.7×124.1 mm (H×V) |
| Outline Depth | 6.0±0.3 mm |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| CLAG045LJ72 | CPT | 4.5" | 480×854 |
| CLAN050WD61 6XM | CPT | 5.0" | 720×1280 |
| CLAD015GC41 AX | CPT | 1.5" | 240×240 |
| CLAA090WK05XN | CPT | 9.0" | 1280×720 |
| CLAC080XA12LW | CPT | 8.0" | 1024×768 |
| CLAD015GB01 AX | CPT | 1.5" | 240×240 |
| CLAG045LG71 XX | CPT | 4.5" | 480×854 |
| CLAG045LH41 AXXA | CPT | 4.5" | 480×854 |
| CLAF020GC21A0 | CPT | 2.0" | 240×320 |
| CLAN080WQ65 XG | CPT | 8.0" | 800×1280 |
| CLAN070NQ06 | CPT | 7.0" | 1024×600 |
