CLAA101ND06CW 10.1 inch, 1024×600 TFT LCD MODULE Normally White Outline 235×143×4.8 mm Frequency 60Hz

CLAA101ND06CW 10.1 inch, 1024×600 TFT LCD MODULE Normally White Outline	235×143×4.8 mm Frequency 60Hz
CLAA101ND06CW 10.1 inch, 1024×600 TFT LCD MODULE Normally White Outline	235×143×4.8 mm Frequency 60Hz

Large Image :  CLAA101ND06CW 10.1 inch, 1024×600 TFT LCD MODULE Normally White Outline 235×143×4.8 mm Frequency 60Hz

Product Details:
Place of Origin: KOREA
Brand Name: TORISAN
Certification: ISO9001
Model Number: TM121SV-02L01
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 2-3 working days after payment confirmation
Payment Terms: T/T, Paypal, Western Union, MoneyGram
Supply Ability: 100 PCS / DAY

CLAA101ND06CW 10.1 inch, 1024×600 TFT LCD MODULE Normally White Outline 235×143×4.8 mm Frequency 60Hz

Description
Panel Brand: CPT Panel Model: TM121SV-02L01
Panel Type: A-Si TFT-LCD Outline: 235×143×4.8 Mm
Surface: Antiglare Frequency: 60Hz
High Light:

industrial touch screen display

,

industrial lcd panel

CLAA101ND06CW 10.1 inch, 1024×600 TFT LCD MODULE Normally White Outline 235×143×4.8 mm Frequency 60Hz



CLAA101ND06CW Basic Information

Panel Model CLAA101ND06CW
Panel Brand CPT
Descrition a-Si TFT-LCD ,10.1 inch, 1024×600
Panel Type a-Si TFT-LCD
Operating Temperature -20 ~ 70 °C
Storage Temperature -30 ~ 80 °C
Vibration Resistance 2.9G (28.4 m/s²)


CLAA101ND06CW Mechanical Features

Dot Resolution 1024(RGB)×600 (WSVGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 117 PPI
Aspect Ratio 16:9 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.0725×0.2088 mm (H×V)
Pixel Pitch 0.2175×0.2088 mm (H×V)
Weight 285g (Typ.)
Surface Antiglare
Active Area 222.72×125.28 mm (H×V)
Bezel Area 226.0×128.5 mm (H×V)
Outline Dimension 235×143 mm (H×V)
Outline Depth 4.5±0.3 mm
Holes & Brackets Without
Landscape or Portrait Landscape type
Touch Panel Without


CLAA101ND06CW Optical Features

Display Mode TN, Normally White, Transmissive
Brightness 500 cd/m² (Typ.)
Contrast Ratio 600 : 1 (Typ.) (Transmissive)
Display Color 262K/16.2M (6-bit / 6-bit + FRC)
Color Gamut 50% NTSC (CIE1931)
Response Time 25 (Typ.)(Tr+Td)
Viewing Angle 70/70/70/50 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction 6 o'clock
White color Chromaticity Wx:0.313; Wy:0.329
White Variation 1.25/1.43 (Typ./Max.)(9 points)
Sunlight Readable N


FAQ

Q1: How do we place an order?

A1: Please kindly send us an email specifying the item No., replacements, quantity, other specifications for the Hard disk to place an order.

Q2: How do we make the payment?

A2: We accept T/T, Western Union, MoneyGram, Paypal.

Q3: What's the delivery time?

A3: The delivery time is normally 1-3 working days after payment.

Q4: How would the goods be shipped?

A4: We ship via DHL, UPS, TNT and others.



Packaging & Delivery

Packaging Details:

Safey package

Plastic trays inside

2 layes of cartons

Fragile sign on top

Can be customize 3.5 inch spare parts auo used lcd panel

Delivery Detail: 1-3 Working Days





We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
