10.4 Inch Innolux LCD Panel N101LGE-L11 With 222.72×125.28 Mm Active Area

10.4 Inch Innolux LCD Panel N101LGE-L11 With 222.72×125.28 Mm Active Area
10.4 Inch Innolux LCD Panel N101LGE-L11 With 222.72×125.28 Mm Active Area

Large Image :  10.4 Inch Innolux LCD Panel N101LGE-L11 With 222.72×125.28 Mm Active Area

Product Details:
Place of Origin: KOREA
Brand Name: INNOLUX
Certification: ISO9001
Model Number: N101LGE-L11
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500PCS/DAY

10.4 Inch Innolux LCD Panel N101LGE-L11 With 222.72×125.28 Mm Active Area

Description
Panel Size: 10.1 Inch Resolution: 1024×600
Active Area: 222.72×125.28 Mm Outline: 235×143×5.2 Mm
Contrast Ratio: 500:1 (Typ.) Frequency: 60Hz
High Light:

tft lcd display

,

innolux lcd screen

Normally White 10.4 inch N101LGE-L11 Innolux Surface Antiglare, Hard coating (3H) Frequency 60Hz


Packaging & Delivery
Packaging: Safety Package For all of our LCD Screen Panel Replacements.
Details: 1. Antistatic bag
2. Layers of cartons
3. Foam Box
4. Carton Box.


N101LGE-L11 Basic Information

Panel Model N101LGE-L11
Panel Brand CHIMEI INNOLUX
Descrition a-Si TFT-LCD ,10.1 inch, 1024×600
Panel Type a-Si TFT-LCD
Operating Temperature 0 ~ 50 °C
Storage Temperature -20 ~ 60 °C


N101LGE-L11 Mechanical Features

Dot Resolution 1024(RGB)×600 (WSVGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 117 PPI
Aspect Ratio 16:9 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.0725×0.2088 mm (H×V)
Pixel Pitch 0.2175×0.2088 mm (H×V)
Weight 180/190g (Typ./Max.)
Surface Antiglare, Hard coating (3H)
Active Area 222.72×125.28 mm (H×V)
Bezel Area 226.34×128.1 mm (H×V)
Outline Dimension 235×143 mm (H×V)
Outline Depth 4.9/5.2 (Typ./Max.) mm
Shape Style Wedge (PCBA Bent, Depth ≥5.2mm)
Holes & Brackets Side mounting holes (4-M2) on left, right bezel
Landscape or Portrait Landscape type
Touch Panel Without


N101LGE-L11 Optical Features

Display Mode TN, Normally White, Transmissive
Brightness 200 cd/m² (Typ.)
Contrast Ratio 500 : 1 (Typ.) (Transmissive)
Display Color 262K (6-bit)
Response Time 3/7 (Typ.)(Tr/Td)
Viewing Angle 45/45/20/45 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction 6 o'clock
White color Chromaticity Wx:0.313; Wy:0.329
White Variation 1.25/1.40 (Max.)(5/13 points)
Sunlight Readable N



Why Choose US:
1. Prompt reply within 12 hours.
2. Understand inquiry in any language.
3. Products with top quality.
4. Very competitive prices.
5. 6-year experience in industrial LCD Screen replacements.
6. Distributor of famous brands Panel: Samsung, LG, Sharp, AUO, TPO, Tianma, Mitsubishi and more.
7. Fabulous after-sale service.

Here comes our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
F050A13-603 Innolux 5.0" 720×1280
V500DK2-QS1 Innolux 50" 3840×2160
M270HGE-P01 Innolux 27.0" 1920×1080
V850DK1-QS1 Rev.C1 Innolux 85" 3840×2160
V580DK1-QS2 Innolux 58" 3840×2160
CP047BN01 Innolux 4.7" 720×1280
PH040NA-01C Innolux 4.0" 480×800
HE080IA-06B Innolux 8.0" 800×1280
V580DK2-QS1 Innolux 58" 3840×2160
P101JEA-3Z1 Innolux 10.1" 1920×1200
P101DBZ-3Z1 Innolux 10.1" 800×1280
