Product Details:
|
| Panel Size: | 15.6 Inch | Resolution: | 1920×1080 |
|---|---|---|---|
| Contrast Ratio: | 500:1 (Typ.) | Frequency: | 60Hz |
| Input Voltage: | 3.3V (Typ.) | ||
| High Light: | tft lcd display,innolux lcd screen |
||
Normally White 15.6 inch N156HGE-EAL Rev.C1 INNOLUX with 344.16×193.59 mm Active Area Frequency 60Hz
N156HGE-EAL Rev.C1 Basic Information
| Panel Model | N156HGE-EAL Rev.C1 |
| Panel Brand | INNOLUX |
| Descrition | a-Si TFT-LCD ,15.6 inch, 1920×1080 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -20 ~ 60 °C |
| Remarks | eDP1.2 |
N156HGE-EAL Rev.C1 Mechanical Features
| Dot Resolution | 1920(RGB)×1080 (FHD) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 141 PPI |
| Aspect Ratio | 16:9 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.05975×0.17925 mm (H×V) |
| Pixel Pitch | 0.17925×0.17925 mm (H×V) |
| Weight | 350/360g (Typ./Max.) |
| Surface | Antiglare (Haze 24%), Hard coating (3H) |
| Active Area | 344.16×193.59 mm (H×V) |
| Outline Dimension | 359.5×224.3 mm (H×V) |
| Outline Depth | 3.05/3.2 (Typ./Max.) mm |
| Shape Style | Slim (PCBA Flat, Depth ≤3.2mm) |
| Holes & Brackets | Face mounting holes (8 pcs) on up, down slugs |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
N156HGE-EAL Rev.C1 Optical Features
| Display Mode | TN, Normally White, Transmissive |
| Brightness | 220 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (Transmissive) |
| Display Color | 262K (6-bit) |
| Color Gamut | 94% NTSC (CIE1931) |
| Response Time | 3/8 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/20/35 (Typ.)(CR≥10) (L/R/U/D) |
| White color Chromaticity | Wx:0.313; Wy:0.329 |
| White Variation | 1.25 (Max.)(5 points) |
| Sunlight Readable | N |
N&S Delivery Details:
1) We are shipping this item to worldwide.
2) Our LCD panel orders processed within 1-3 working days of payment verification.
3) If you have not received the item on the Delivery Time. Please contact us. We will track the shipment and get back to your as soon as possible with a reply. Our goal is customer satisfaction.
5) We use the professional & safe package for our LCD screen replacements for you: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
6) We will keep you updated for the Tracking NO. after we ship out the parcel to you.
7) Feel free to contact to us if there is any problems during the shipment process.
We Can Do for You:
1) One-to-one service with efficient & professional support;
2) Protection of your design and all your private information;
3) We could supply different hard disk for you.
4) Quality stability, can to provide certification of products;
5) Convenient payment methods: PayPal, T/T and Western Union;
6) Speedy shipment: we could arrange the shipment within 1-3 business days.
7) Quality & Service: Our priority has always been providing our clients with great quality products and superior customer service.
8) Unbeatable Prices: We continuously strive to find ways of reducing our production costs, and passing the savings to you.
N156HGE-EAL Rev.C1 Backlight System
| Lamp Position | Edge light type |
| Lamp Type | WLED |
| Lamp Life Time | 15K(Min.) (Hours) |
| Lamp Voltage | 26/29/30V (Min./Typ./Max.) |
| Lamp Current | 110mA (Typ.) |
| Lamps Power Consumption | 3.19/3.3W (Typ./Max.) |
| Interface Type | Included in panel signal interface |
| Lamp Driver Board | 4.1W (Max.) |
