Product Details:
|
| Panel Size: | 3.5 Inch | Resolution: | 320×240 |
|---|---|---|---|
| Active Area: | 70.08×52.56 Mm | Outline: | 76.9×63.9×1.47 Mm |
| Contrast Ratio: | 350:1 (Typ.) | Response Time: | 10/15 (Typ.)(Tr/Td) |
| High Light: | tft lcd display,lcd display panel |
||
Normally White LQ035NC121 INNOLUX 3.5 inch 320×240 Active Area 70.08×52.56 mm Display Colors 16.7M , CIE1931 60%
LQ035NC121 Basic Information
| Panel Model | LQ035NC121 |
| Panel Brand | ChiHsin |
| Descrition | a-Si TFT-LCD ,3.5 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
LQ035NC121 Mechanical Features
| Dot Resolution | 320(RGB)×240 (QVGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 115 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.073×0.219 mm (H×V) |
| Pixel Pitch | 0.219×0.219 mm (H×V) |
| Active Area | 70.08×52.56 mm (H×V) |
| Outline Dimension | 76.9×63.9 mm (H×V) |
| Outline Depth | 1.47±0.2 mm |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
LQ035NC121 Optical Features
| Display Mode | TN, Normally White, Transmissive |
| Brightness | 0 cd/m² |
| Contrast Ratio | 350 : 1 (Typ.) (Transmissive) |
| Display Color | 16.7M () |
| Color Gamut | 60% NTSC (CIE1931) |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Viewing Angle | 55/55/45/50 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction | 6 o'clock |
| White color Chromaticity | Wx:0.310; Wy:0.330 |
| Transmissivity | 7.4% (Typ.)(with Polarizer) |
| Sunlight Readable | N |
Packaging & Delivery
Packaging Details:
Safey package
Plastic trays inside
2 layes of cartons
Fragile sign on top
Can be customize 3.5 inch spare parts auo used lcd panel
Delivery Detail: 1-3 Working Days
