Transmissive HJ070NA-13A Innolux LCD Panel , 7 Inch Lcd Display Panel

Transmissive HJ070NA-13A Innolux LCD Panel , 7 Inch Lcd Display Panel

Transmissive HJ070NA-13A Innolux LCD Panel , 7 Inch Lcd Display Panel

Product Details:

Place of Origin: KOREA
Brand Name: INNOLUX
Certification: ISO9001
Model Number: HJ070NA-13A

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: Western Union, T/T, MoneyGram, T/T
Supply Ability: 500PCS/DAY
Contact Now
Detailed Product Description
Panel Type: A-Si TFT-LCD Panel Size: 7.0 Inch
Resolution: 1024×600 Outline: 165.75×105.39×2.65 Mm
Active Area: 153.6×90 Mm Contrast Ratio: 700:1 (Typ.)

New and original HJ070NA-13A 7.0 inch Outline 165.75×105.39×2.65 mm TN, Normally White, Transmissive



Up to now, over hundreds of aerospace, power management, network, communications, instrumentation and consumer electronics, etc are benefiting from our service and LCD screen panels.

We can do for you:

  1. Provide excellent LCD screen replacements with competitive price.
  2. Safe, quick and efficient supply chain.
  3. Plenty of stocks. Branded ones include LCD Screen panels for LG, Samsung, Sharp, BOE, Chimei and so on.
  4. Your problems will be replied within 24 hours.

Packing & Delivery for our LCD Screen Panel Replacements:

  1. Anti-static Bag Packing.
  2. Anti-Shock Bubble Bag Packing
  3. Foam and Hard Carton Packing
  4. Picked up by forward and delivered by express services.

HJ070NA-13A Basic Information

Panel Model HJ070NA-13A
Panel Brand CHIMEI INNOLUX
Descrition a-Si TFT-LCD ,7.0 inch, 1024×600
Panel Type a-Si TFT-LCD
Operating Temperature -10 ~ 50 °C
Storage Temperature -20 ~ 60 °C
Remarks CABC


HJ070NA-13A Mechanical Features

Dot Resolution 1024(RGB)×600 (WSVGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 169 PPI
Aspect Ratio 17:10 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.050×0.150 mm (H×V)
Pixel Pitch 0.150×0.150 mm (H×V)
Weight 92.8g (Typ.)
Surface Clear
Active Area 153.6×90 mm (H×V)
Bezel Area 156.4×92.8 mm (H×V)
Outline Dimension 165.75×105.39 mm (H×V)
Outline Depth 2.45±0.2 mm
Holes & Brackets Without
Landscape or Portrait Landscape type
Touch Panel Without


HJ070NA-13A Optical Features

Display Mode TN, Normally White, Transmissive
Brightness 250 cd/m² (Typ.)
Contrast Ratio 700 : 1 (Typ.) (Transmissive)
Display Color 262K/16.7M (6-bit / 6-bit + Hi-FRC)
Color Gamut 70% NTSC (CIE1931)
Response Time 10/15 (Typ.)(Tr/Td)
Viewing Angle 70/75/75/75 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction 6 o'clock
White color Chromaticity Wx:0.310; Wy:0.330
White Variation 1.33/1.43 (Typ./Max.)(9 points)
Sunlight Readable N


Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
HE080IA-01D Innolux 8.0" 1024×768
HE070IA-04F Innolux 7.0" 800×1280
N173FGE-P23 Innolux 17.3" 1600×900
N116BGE-P32 Innolux 11.6" 1366×768
N116BGE-P42 Innolux 11.6" 1366×768
M220ZGE-P01 Innolux 22.0" 1680×1050
V236BJ1-P01 Innolux 23.6" 1366×768
CT024TN01 V.X Innolux 2.4" 240×320
M215HGE-P02 Innolux 21.5" 1920×1080
F03003-05L Innolux 3.0" 320×240
EE027NA-02A Innolux 2.7" 320×240

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
