Normally White 15.6 inch N156BGA-EA2 1366×768 resolution Active 344.232×193.536 (H×V) Good View at 6 o'clock

Normally White 15.6 inch N156BGA-EA2 1366×768 resolution Active 344.232×193.536 (H×V) Good View at 6 o'clock
Normally White 15.6 inch N156BGA-EA2 1366×768 resolution Active 344.232×193.536 (H×V) Good View at 6 o'clock Normally White 15.6 inch N156BGA-EA2 1366×768 resolution Active 344.232×193.536 (H×V) Good View at 6 o'clock Normally White 15.6 inch N156BGA-EA2 1366×768 resolution Active 344.232×193.536 (H×V) Good View at 6 o'clock

Large Image :  Normally White 15.6 inch N156BGA-EA2 1366×768 resolution Active 344.232×193.536 (H×V) Good View at 6 o'clock

Product Details:
Place of Origin: KOREA
Brand Name: INNOLUX
Certification: ISO9001
Model Number: N156BGA-EA2
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: Western Union, T/T, MoneyGram, T/T
Supply Ability: 500PCS/DAY

Normally White 15.6 inch N156BGA-EA2 1366×768 resolution Active 344.232×193.536 (H×V) Good View at 6 o'clock

Description
Panel Type: LCM, A-Si TFT-LCD Panel Size: 15.6 Inch
Resolution: 1366×768 Active: 344.232 × 193.536 (H×V)
Luminance: 220 Cd/m² (Typ.) Good View At: 6 O'clock
High Light:

tft lcd display

,

innolux lcd screen

Normally White 15.6 inch N156BGA-EA2 1366×768 resolution Active 344.232×193.536 (H×V) Good View at 6 o'clock



  • Manufacturer INNOLUX
  • Model Name N156BGA-EA2
  • Screen Size 15.6 inch
  • Screen Type LCM, a-Si TFT-LCD
  • Pixel Number 1366(RGB)×768 (WXGA)
  • Arrangement RGB Vertical Stripe
  • Active Area(mm) 344.232 × 193.536 (H×V)
  • Outline(mm) 359.5 × 223.8 × 3.2 (H×V×D)
  • Bezel Area(mm) 347.36 × 196.84 (H×V)
  • Treatment Antiglare, Hard coating (3H)
  • Luminance 220 cd/m² (Typ.)
  • Contrast Ratio 600 : 1 (Typ.) (TM)
  • Viewing Angle 45/45/20/45 (Typ.)(CR≥10)
  • Response 3/7 (Typ.)(Tr/Td) ms
  • Good View at 6 o'clock
  • Work Mode TN, Normally White, Transmissive
  • Color Depth 262K 45% (CIE1931)
  • Backlight WLED , 15K hours , With LED Driver
  • Outline ShapeSlim (PCBA Flat, Depth ≤3.2mm)
  • Refresh Rate60Hz
  • TouchscreenWithout
  • Signal Type
  • eDP (1 Lane) , Connector , 30 pins
  • Voltage Supply
  • 3.3V (Typ.)
  • Max. Ratings
  • Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

Excellent service on before-sale, on-sale and after-sale

1. We provide one year warranty, will provide the after-sale service for you if any quality problems.

2.Your inquiry related to our products or prices will be replied in 24 hours.

3. We will track the shipping status time by time so that buyer can receive our goods in time and safely.



Our service

1. Agent Brand:

* Our sourcing line contained but not limited to Samsung, LG, Sharp, AUO, Tianma, Chimei, Hannstar, Innolux, BOE and more bands tft lcd moulds from 2010, you can get the most competitive price for real products;

2. Quality to be guaranteed:

* All the panels are 100% original and brand new, no fake panels exists.Take the lcd screen from us, you can enjoy the real panels directly from original factory;

* Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the LCD panels packages have labels and serial number, you can check them;

3. Quickly delivery:

* We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly.

4. long-term partner:

* Products are sold to more than 20 countries.

5. Super After-Sale service:

* One year warranty .

6. The best TFT LCD solution:

*more tft lcd model detail information for the LCD screens including size, resolution, brightness, operating temperature or life time etc in our web site.



Here comes our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
AT070TN90 Innolux 7.0" 800×480
PH030NA-04A Innolux 3.0" 240×400
EE090NA-01C Innolux 9.0" 1280×800
EE080NA-06A Innolux 8.0" 800×600
AT080TN60 Innolux 8.0" 800×480
EE070NA-01L Innolux 7.0" 1024×600
EE070NA-01D Innolux 7.0" 1024×600
AT070TN90 V.1 Innolux 7.0" 800×480
AT070TN00 V.1 Innolux 7.0" 480×234
AT050TN30 Innolux 5.0" 480×272
LW700AT6005 Innolux 7.0" 800×480
