N156BGE-E32 Innolux LCD Panel 15.6 Inch With 344.232×193.536 Mm Active Area

N156BGE-E32 Innolux LCD Panel 15.6 Inch With 344.232×193.536 Mm Active Area
N156BGE-E32 Innolux LCD Panel 15.6 Inch With 344.232×193.536 Mm Active Area

Large Image :  N156BGE-E32 Innolux LCD Panel 15.6 Inch With 344.232×193.536 Mm Active Area

Product Details:
Place of Origin: Japan,Korea
Brand Name: INNOLUX
Certification: ISO9001
Model Number: N156BGE-E32
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: T/T, Western Union, MoneyGram, Paypal
Supply Ability: 100 PCS PER DAY

N156BGE-E32 Innolux LCD Panel 15.6 Inch With 344.232×193.536 Mm Active Area

Description
Panel Type: A-Si TFT-LCD Panel Size: 15.6 Inch
Resolution: 1366×768 Active Area: 344.232×193.536 Mm
Outline: 359.5×223.8×3.6 Mm Contrast Ratio: 500:1 (Typ.)
Frequency: 60Hz
High Light:

lcd display panel

,

innolux lcd screen

Normally White N156BGE-E32 15.6 inch 1366×768 resolution Active Area 344.232×193.536 mm Outline 359.5×223.8×3.6 mm



N156BGE-E32 Basic Information

Panel Model N156BGE-E32
Panel Brand INNOLUX
Descrition a-Si TFT-LCD ,15.6 inch, 1366×768
Panel Type a-Si TFT-LCD
Operating Temperature 0 ~ 50 °C
Storage Temperature -20 ~ 60 °C
Remarks eDP1.2


N156BGE-E32 Mechanical Features

Dot Resolution 1366(RGB)×768 (WXGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 100 PPI
Aspect Ratio 16:9 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.084×0.252 mm (H×V)
Pixel Pitch 0.252×0.252 mm (H×V)
Weight 360/380g (Max.)
Surface Antiglare, Hard coating (3H)
Active Area 344.232×193.536 mm (H×V)
Bezel Area 346.2×195.5 mm (H×V)
Outline Dimension 359.5×223.8 mm (H×V)
Outline Depth 3.3/3.6 (Typ./Max.) mm
Shape Style Flat (PCBA Flat, Depth 3.4~4.0mm)
Holes & Brackets Face mounting holes (8 pcs) on up, down slugs
Landscape or Portrait Landscape type
Touch Panel Without


N156BGE-E32 Optical Features

Display Mode TN, Normally White, Transmissive
Brightness 220 cd/m² (Typ.)
Contrast Ratio 500 : 1 (Typ.) (Transmissive)
Display Color 262K (6-bit)
Color Gamut 45% NTSC (CIE1931)
Response Time 3/8 (Typ.)(Tr/Td)
Viewing Angle 45/45/20/45 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction 6 o'clock
White color Chromaticity Wx:0.313; Wy:0.329
White Variation 1.25 (Max.)(5 points)
Sunlight Readable N


Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
P070ACZ-3Z1 Innolux 7.0" 600×1024
F03511-02U Innolux 3.5" 320×480
F05007-01Z Innolux 5.0" 720×1280
EE101IA-01C Innolux 10.1" 1280×800
EB070NA-09A Innolux 7.0" 800×480
V500DK2-PS1 Innolux 50" 3840×2160
86A04310-00 Innolux 4.3" 480×272
HE070IA-04R Innolux 7.0" 800×1280
HE070IA-04E Innolux 7.0" 800×1280
HE080IA-01E Innolux 8.0" 1024×768
M200FGE-P02 Innolux 20.0" 1600×900

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
