Product Details:
|
| Panel Type: | LTPS TFT-LCD | Panel Size: | 8.4 Inch |
|---|---|---|---|
| Resolution: | 800×600 | Display Mode: | TN, Normally White, Transmissive |
| Active Area: | 170.4×127.8 Mm | Outline: | 199.5×149.5 Mm |
| High Light: | industrial lcd screen,industrial lcd panel |
||
LT084AC27500 8.4 inch Outline 199.5×149.5 mm Display Colors 262K (6-bit) TN, Normally White, Transmissive
LT084AC27500 Basic Information
| Panel Model | LT084AC27500 |
| Panel Brand | Toshiba Mobile Display |
| Descrition | LTPS TFT-LCD ,8.4 inch, 800×600 |
| Panel Type | LTPS TFT-LCD |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Remarks | Mounting compatible with LTM08C351 series and LTA084C270F. |
LT084AC27500 Mechanical Features
| Dot Resolution | 800(RGB)×600 (SVGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 119 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.071×0.213 mm (H×V) |
| Pixel Pitch | 0.213×0.213 mm (H×V) |
| Weight | 470 (Typ.) |
| Active Area | 170.4×127.8 mm (H×V) |
| Bezel Area | 174.8×133.7 mm (H×V) |
| Outline Dimension | 199.5×149.5 mm (H×V) |
| Outline Depth | 13.0±0.5 mm |
| Holes & Brackets | Face mounting holes (4 pcs) |
| Landscape or Portrait | Landscape type |
| Touch Panel | Embeded (4-wire Resistive) |
FAQ
Q1: What's the quality of your Hard Disk?
A: Various brands for hard disk etc. We are available to meet your different requirements.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 12-month warranty after shipping to assure you a stable performance.
Q4: How long is the lead time?
A: The lead time is about 2-3 working days after receipt of payment.
Q5: Do you accept sample order?
A:Yes, sample order is welcome.
Q6: How can I get the quotation?
A: Please enquire via Skype, Email, Whatsapp or telephone. You will get reply within 24 hours.
Packaging & Delivery
Packaging: Safety Package For all of our LCD Screen Panel Replacements.
Details: 1. Antistatic bag
2. Layers of cartons
3. Foam Box
4. Carton Box.
